RUGGEDCOM RX1536
Equipment Manual, 10/2023, C79000-G8976-1488-07
European-style (Euroblock) Terminal Block
1
Positive (+) Terminal
2
Negative (-) Terminal
3
Ground Terminal
4
Figure 2.11
DC Terminal Block Wiring – European-style (Euroblock) Terminal Block for
-12P, -24P and -48P Power Supplies
4
2
Not Connected
1
Removable Screw Terminal Block
2
Non-removable Screw Terminal Block
3
Positive (+) Terminal
4
Negative (-) Terminal
5
Ground Terminal
6
Figure 2.12
DC Terminal Block Wiring – Screw Terminal Block for -12P, -24P and -48P
Power Supplies
1
2
3
4
1
5
1
6
Installing the Device
2.5.2 Connecting Low DC Power
3
4
5
6
19
