4.4 Installing/Removing Power Modules
4.
5.
Installing a Module
To install a line module, do the following:
1.
2.
3.
4.
5.
4.4

Installing/Removing Power Modules

The RUGGEDCOM RX1536 supports dual redundant power supply modules.
1
30
Chassis
2
Screw
3
Figure 4.2 Removing a Module
Install a new module or a blank module (to prevent the ingress of dust and dirt).
[Optional] If necessary, install the device in the rack.
[Optional] If the device is installed in a rack, remove it from the rack.
Remove the current module from the slot.
Insert the new module into the slot.
1
2
3
Module
1
Chassis
2
Screw
3
Figure 4.3 Installing a Module
Tighten the screws to secure the module.
[Optional] If necessary, install the device in the rack.
1
Slot PS1
RUGGEDCOM RX1536
