Boiler regulator
ecoMAX860P3-C TOUCH
FOR AUTOMATIC SOLID FUEL FIRED BOILERS
ecoSTER TOUCH**
ecoNET300**
ecoNET.apk
www.econet24.com
** - room panel ecoSTER TOUCH and internet module ecoNET300 - not the standard
equipment of the controller.
INSTRUCTION INSTALLATION AND OPERATING MANUAL
ISSUE: 1.0
APPLIES TO
SOFTWARE:
MODUL
PANEL
A/B
v01.XX.XX
v01.XX.XX
functions available in the
additional module B
03-2017
Advertisement
Table of Contents
Related Manuals for Plum ecoMAX860P3-C TOUCH
Summary of Contents for Plum ecoMAX860P3-C TOUCH
- Page 1 Boiler regulator ecoMAX860P3-C TOUCH FOR AUTOMATIC SOLID FUEL FIRED BOILERS ecoSTER TOUCH** ecoNET300** ecoNET.apk www.econet24.com functions available in the additional module B ** - room panel ecoSTER TOUCH and internet module ecoNET300 - not the standard equipment of the controller.
-
Page 3: Table Of Contents
CONTENTS 12.11 C ......30 HECKING TEMPERATURE SENSORS 12.12 C ..30 ONNECTION OF MIXERS ROOM THERMOSTAT RECOMMENDATIONS REGARDING SAFETY ..4 12.13 C ..30 ONNECTION OF BOILER S ROOM THERMOSTAT 12.14 C ......31 ONNECTION OF RESERVE BOILER GENERAL INFORMATION ........ -
Page 4: Recommendations Regarding Safety
dusts or liquids can cause fire or RECOMMENDATIONS REGARDING explosion. Thus, the regulator should be separated from flammable dusts SAFETY and gases, e.g. by means of an Requirements concerning safety appropriate body. described in detail in individual chapters of this manual. Apart from them, the following ... -
Page 5: General Information
sale device, attached General information documentation should be handed over to the The regulator is a modern electronic device new user / owner. designed to control automatic solid fuel fired Applied symbols boilers with ignition. Flame detection occurs with an optical flame brightness sensor. In this manual the following graphic symbols The regulator can be used to control the are used:... -
Page 7: User Settings
USER SETTINGS ecoMAX860P3-C TOUCH... -
Page 8: User Menu - Structure
USER MENU - STRUCTURE HUW settings* Main menu HUW preset temperature Information HUW pump mode: Boiler settings HUW settings* Priority Mixer 1-5 settings* No priority Summer/Winter HUW hysteresis General settings HUW disinfection Manual control HUW night time decrease: ... -
Page 9: Operating The Regulator
Operating the regulator Description of display main window OPERATION 1. mode of regulator operation: FIRING-UP, - of preset boiler temperature for INCANDESCENCE, OPERATION, active time intervals, SUPERVISION, BURNING OFF, CLEANING, STOP 2. preset boiler temperature - increase of preset boiler temperature 3. -
Page 10: Switching On And Off The Boiler
(feeding time) is reduced to 10% of the dose Switching on and off the boiler in the first attempt. Consecutive attempts visualised Make sure fuel is present in the tank and tank hatch is closed. Now boiler may be numbers next to the lighter symbol switched on. -
Page 11: Regulation Mode
Regulation mode mode does not require setting the H1 and H2 hysteresis. There regulation modes If only the HUW is heated (summer stabilizing the set temperature of the boiler: mode), it is recommended to set the Standard and FuzzyLogic regulator to Standard mode. Boiler settings →... -
Page 12: Burning Off
The controller exits the Supervision mode value boiler hysteresis (Boiler hysteresis), without user intervention after exceeding the if the boiler is set to work with a buffer - preset boiler temperature of 10 ° C. decrease upper buffer temperature For the setting Supervision time = 0, below the preset value (Buffer loading start the regulator skips the SUPERVISION... -
Page 13: Setting Huw Preset Temperature
set simultaneous operation of the CH and HUW Settings → Circulation pumps night HUW pump, using parameter No priority. time decrease 8.14 Setting HUW preset temperature Service settings → CH and HUW settings Preset temperature defined Setting circulating pump control parameter: analogical... -
Page 14: Weather Controlled
Preset room temperature = 20°C + heating Preset mixer temperature will be increased curve translation. by (22°C - 20°C) x 15/10 = 3°C. Example: It is necessary to find appropriate value of In this setup, it is possible to connect a room the Room temp. -
Page 15: Description Of Night Time Decrease Settings
Guidelines selection appropriate Night time decreases defined heating curve: separately for every day of the week set - if the outdoor temperature drops, and the Schedule. room temperature increases, the selected Set the start and end of the time interval for heating curve value is too high, a reduction value in the range 1..24 hours. -
Page 16: Feeder Efficiency Test
Once selected and confirmed YES, fuel level (contacts open) the regulator activates the is set to 100%. additional tank External feeder Note: Fuel may be replenished at any time operation time to refill the main fuel tank. without a need to wait for complete empty This parameter can be found in: Service fuel tank. -
Page 17: Internet Module
indication etc. 8.28 Internet module controller work together with ecoNET300 internet module. enables online control and supervision over controller help website www.econet24.com. convenient mobile application ecoNET.apk. Mobile application can be downloaded free of charge from the website:... -
Page 19: Installation And Service Settings
INSTALLATION AND SERVICE SETTINGS ecoMAX860P3-C TOUCH... -
Page 20: Hydraulic Diagrams
Hydraulic diagrams The presented hydraulic diagrams does not replace central heating engineering design and may be used for information purposes only!. Diagram with 4-way control valve for central heating circuit: 1 – boiler, 2 – controller, 3 - water temperature sensor returning to the boiler, 4 – boiler temperature sensor, 5 – exhaust temperature sensor (temperature monitoring only), 6 –... - Page 21 Diagram with two adjustable heating circuits and the HUW container:1 – boiler, 2 – heat exchanger, 3 – controller, 4 – boiler temperature sensor, 5 – exhaust temperature sensor (temperature monitoring only), 6 – boiler pump, 8 – HUW pump, 9 – HUW container, 10 – HUW temperature sensor, 11 – mixer pump, 12 –...
- Page 22 Diagram with heat buffer: 1 – boiler, 2 – burner, 3 – controller, 4 – boiler temperature sensor, 5 – exhaust temperature sensor, 6 – boiler pump, 7 – heat buffer, 8 – HUW pump , 9 - mixing valve actuator, 10 - mixer temperature sensor, 11 - mixer pump, 12 - upper sensor of buffer temperature, 13 - lower sensor of buffer temperature, 14 - ecoSTER TOUCH room control panel, 15 - thermostatic three-way valve to the return protection, 16 –...
-
Page 23: Technical Data
During transport, device cannot Technical data exposed to vibrations greater than those typical of normal road transport. Voltage 230V~, 50Hz Current consumed by 0,04A REGULATOR INSTALLATION regulator Maximum rated current 6(6)A 12.1 Environmental conditions Regulator protection rating IP20 Due to the risk of fire is prohibited to use the Ambient temperature 0..50C controller... -
Page 24: Mounting Of Working Module
Drill a hole in the mounting plate acc. the below drawing. To remove the control panel (1) from the housing - insert flat elements (2) into indicated slots to release housing catches and remove the panel (1). 12.4 Mounting of working module Working module has to be built-into the master equipment. -
Page 25: Ip Protection Rate
Protect connecting wires from tearing, accordance with this drawing, the device has protection rate IP 20 from the front side of loosening and tensioning or built them in in the executive module enclosure (specified on such a way that no load is exerted on them. the rating plate). -
Page 26: Connecting Electrical System
12.6 Connecting electrical system accordance with the picture below: a – Regulator is designed to be fed with 230V~, properly secured, b – improperly secured. 50Hz voltage. The electrical system should three core (with protective wire PE), Insulated clamp sleeve, 6mm lenght. -
Page 27: Electric Scheme
12.7 Electric scheme Wiring diagram controller ecoMAX860P3-C TOUCH: λ – Lambda module, B – module B to support additional heat circuits, BH – upper buffer temperature sensor type CT4, BL – lower buffer temperature sensor type CT4, PLS - fuel level sensor, T - standard room thermostat (No/Nc), H –... - Page 28 CT4, M2 – regulated circuit (mixer 3) sensor temperature type CT4, RM2 – mixer 2 room thermostat, RM3 – mixer 3 room thermostat. L N PE - power supply 230V~, GR – grounding bar, PM2/PM3 – mixer 2/3 pump, SM2/SM3 – mixer 2/3 servo, CPU – controller, A – ecoMAX860P3-C TOUCH regulator module A.
-
Page 29: Connection Of Temperature Sensors
under a roof. The sensor should not be 12.8 Connection of temperature sensors exposed to direct sunlight and rain. The Sensor wires may be extended using wires of sensor should be fitted at least 2 m above cross-section area not less than 0.5mm the ground, far from windows, chimneys and Total length of wires of each sensor should other heat sources which could disturb the... -
Page 30: Checking Temperature Sensors
CT2S-2 (exhaust) Temp. Min. Rated Max. °C Ω Ω Ω 999.7 1000.0 1000.3 1096.9 1097.3 1097.7 1193.4 1194.0 1194.6 1384.2 1385.0 1385.8 1478.5 1479.4 1480.3 1572.0 1573.1 1574.2 CT6-P (weathers) Temp. Min. Nom. Max. °C Ω Ω Ω 901,6 901,9 902,2 921,3 921,6... -
Page 31: Connection Of Reserve Boiler
boiler), set the Pump Off by therm. value to YES. Service Settings → Boiler Settings → Pump Off by thermostat 12.14 Connection of reserve boiler The regulator can control a reserve boiler (gas- or oil-), eliminating the necessity of enabling or disabling this boiler manually. Connection to a reserve boiler, should only be made by a qualified fitter, in accordance with the technical documentation of this... -
Page 32: Connection Of Mixer
Connect alarm annunciator as shown in determine direction servo closing/ below fig. through the relay. opening. For this purpose, set the selector Alarm signalling may be deactivated by located on the housing of the servo to setting the Output H function to Alarms. manual control and find the positions in Service Settings →... - Page 33 Cross-section area of wires used to connect ecoSTER TOUCH control panel should be 0,5mm Max. length of wires should not exceed 30 m. This length may be longer if the wires used have cross-section area larger than 0,5mm Four-wire connection Connection –...
-
Page 34: Service Menu
Lambda sensor* 13 SERVICE MENU Operation with Lambda sensor Airflow correction range Service settings Parameter A,B,C Lambda Burner settings Minimum airflow output Boiler settings Fuel shortage detection time CH and HUW settings Max. burner temperature Buffer settings* Operation time of external feeder Mixer 1-5 settings* Output H... - Page 35 Output H Output H (mod B/C)* Reserve Boiler Alarms unavailable adequate sensor additional module connected parameter is hidden.
-
Page 36: Service Settings
14 SERVICE SETTINGS 14.1 BURNER Firing-up It is a verification time to check, if the furnace is burning or not. In this Ignition test time time only ventilator is working. Fuel dose during firing up. Concerns first testing firing up. Next tests fuel ... -
Page 37: Boiler
Fan power in % during furnace cleaning in Burning off mode and Firing- Cleaning blowing up mode. Time work rotary output during cleaning the burner and the time break of Rotary cleaning cycle rotary cycle during cleaning the burner. Supervision When the time of supervision will pass by, the controller then goes into BURNING OFF mode and then into STOP mode. -
Page 38: And Huw
This parameter turns on/off the boiler return protection function, which is Return protection 4D being done by mixing valve together with electric actuator. Attention: do not activate this function when there is no actuator installed on the valve! The electric actuator will return to its normal operation with Return ... -
Page 39: Buffer
temperature. This issue is exceptionally important in HUW pump operation in SUMMER mode, when pump is deactivated. To cool off the boiler HUW pump operation can be prolonged by HUW operation extension. It is the time between periods of circulation pump operation and it is Circulation pump standstill time defined by the parameter Circulation standstill time (recommended setting is between 15-40 min.) The circulation pump is operating in... -
Page 40: H Output
when the Mixer support = Floor then the mixer pump will shut down by max. mixer temperature, which protects the floor against destruction. For the floor heating it should be set for the value below 45-50˚C or even lower, when the thermal resistance of this floor is lower. -
Page 41: Description Of Alarms
protection. 15 DESCRIPTION OF ALARMS 15.3 Boiler temperature sensor 15.1 Exceeding max. boiler temp. damage There is a two-stage safety precaution for An alarm occurs with the damages of boiler boiler overheating. First of all, i.e. after temperature sensor as well with exceeding exceeding Boiler cooling temperature the measurement range of this sensor. -
Page 42: Boiler Overheating Stb, Open Contact
Note: operating emergency cause activating automatic boiler mode is allowed only under user operation, there is only a warning displayed. supervision and until the arrival of 16 OTHERS the service team to remove the failure. If user supervision is not 16.1 Power supply decay possible,... -
Page 43: Lambda Sensor
17 Lambda sensor Burner efficiency increased connecting additional Lambda sensor module. Connect the module according to electric scheme. Lambda sensor is to be activated in: Service settings → Burner settings → Lambda sensor If parameter Operation with Lambda sensor is set on ON then the controller will operate using Lambda sensor readings. - Page 48 Wspólna 19, Ignatki 16-001 Kleosin Poland plum@plum.pl www.pum.pl www.plumelectronics.eu...
