Plane
Creation Description
Method
3 Points Fit ● The plane is generated by 3 points not co-linear.
● Click on the data to select one point or click on a previous
created feature point.
● In the Choice list select one of the points to reselect it.
Feature creation failed! Error code 6: the points selected
are co-linear.
Point-Line Fit ● The plane generated includes the point and the line (The
line should be created in advanced).
● Click on the line previously created or select it from the
drop-down.
● Click on the data to select a point or click on a feature point
previously created.
Feature creation failed! Error code 6: the point selected
belongs to the line.
Best Fit ● The plane generated is the position with the smallest
deviation from the selected area.
Note
The 3 points can't be on the
same line.
Line should be created in
advanced
-
