Shining 3D EXScan H User Manual page 48

Project setting
White light mode
Alignment
Alignment Instruction
Feature Uses object geometric features for auto aligning during scanning. Rich features on the object are
required for this mode.
Texture Uses objects surface texture to align the scans. Compared with feature alignment, texture
alignment takes longer and consumes more memory. It is recommended to use the texture
alignment only in cases where the object's geometrical features are insufficient.
Global Uses global markers file to help align the scans. You may add an existed global markers file or
Markers scan one.
Hybrid Uses features, markers to align the scans. Use the function to avoid alignment error in some
target parts. By this alignment, we do not need to place the markers all over the part, but only on
the region where has less geometry. Global markers files can be imported to assist in scanning
and aligning.
Resolution
Resolution
0.2mm ~ 3mm
Texture
Texture
Texture scan on
Texture scan off
Instruction
0.5mm by default
Icon Instruction
Will capture texture data.
Will not capture texture data.
