UG-364
TWO INSTALLATION FREQUENTLY ASKED
QUESTIONS
Q: How can I confirm that the hardware was correctly installed
on the PC?
A: To confirm the hardware was correctly installed on the PC,
use the following steps:
1.
Right-click My Computer and left-click Properties.
2.
Go to the Hardware tab, and click Device Manager (see
Figure 18).
Figure 18. System Properties
3.
Scroll to Universal Serial Bus controllers and expand the
root directory (see Figure 19). When the
correctly installed, each time the USB cable connecting the
evaluation board to the computer is plugged in, the items
within the Universal Serial Bus controllers are refreshed.
Figure 19 shows what to expect when the
board is correctly installed and when the evaluation board and
USB cable are connected correctly to the computer. The root
directory is subsequently refreshed when the USB cable is
unplugged from evaluation board, and the
kit icon is removed from the main root.
EXPAND ROOT
DIRECTORY
Rev. 0 | Page 10 of 28
Evaluation Board User Guide
AD5933
Figure 19. Correctly Installed Hardware
hardware is
AD5933
evaluation
AD5933
evaluation
