C
ONTROL
For most routine installations, the "Quick Start" option will allow for enabling a majority of the
options available with the NX-8, when communicating in Contact ID or SIA formats and without
partitioning. The "Quick Start" locations can be identified by the
Telephone number 1
LOCATION 0 - PHONE N° 1 (20 segments, numerical data)
The first telephone number is programmed in location 0. A "14" indicates the end of the phone
number. Delays of four seconds can be programmed at any point in the phone number by
programming a "13" in the appropriate segment. The system will always wait for a dial tone,
unless the first digit of the phone number is a "13"; in this case, it will only delay. Tone (DTMF)
dialling is default. If you want pulse tone dialling, program a "15" in the segment where pulse
dialling should begin. If the entire number should be pulse dialling, program a "15" in the first
segment. Program an "11" for a "*", and a "12" for a "#".
Note: a zero is programmed as a "0".
LOCATION 1 - ACCOUNT CODE FOR PHONE N° 1 (6 segments, numerical data)
Location 1 is used to program the account code that is sent when phone N°1 is dialled. A zero
in the account code is programmed as a "0". A "10" indicates the end of the account code, so
program a "10" in the segment immediately after the last digit of the account code. If the
account code is 6 digits long, program all 6 segments.
LOCATION 2 - COMMUNICATOR FORMAT FOR PHONE N° 1 (1 segment, numerical data)
Location 2 contains the communicator format used to transmit to the receiver that is
connected to phone N°1. Consult the instructions for your central station receiver to
determine which format is compatible. Select a format from the list on the following page. If
you require a format other than those listed, review the override options described in location
18 in order to create the appropriate format. In order to create a special format, a "15" must
be programmed in location 2 in addition to the entries in location 18. If this location contains a
"0", the built-in communicator will be disabled, and the NX-8 will function as a 'local only'
control.
LOCATION 3 - DIAL ATTEMPTS/BACKUP CONTROL FOR PHONE N° 1 (2 segm., numerical data)
Segment 1- Dial attempts: Location 3, segment 1 is used to enter the number of dial attempts
(1 to 15) which the communicator will make to phone N°1 before it ends the notification
process. Factory default is "8" and the communicator will make 8 attempts to the first number.
There will be a waiting time of 12 seconds between the first two dial attempts, and a
waiting time of 60 seconds between each subsequent dial attempt.
NX-8-EUR Installation manual
P
ANEL PROGRAMMING LOCATIONS
Page 35
symbol.
02/07/06
