Step 3
continued
When installing the wired door sensors, make sure the arrow on the
P
wired sensor
as possible.
Sensors can be positioned
on either left or right side
(see next page).
aligns to the arrow of the sensor magnet
2-3/8" (60mm)
Foam pad
2-3/4" (70mm)
PREPARING WIRED DOOR SENSOR
The sensors need to be as
close to level as possible. If
needed, use the adhesive
foam pad(s) to adjust the
height of the wired sensor.
8
Q
as close
(P)
3/4" (20mm)
Right
or
Left
(Q)
