Step 4
Plug the cable coming through mounting plate
F
assembly as shown. Tuck cable under eyelet hooks and route to
the right on interior assembly
X
X
Y
Plug into
red side of plug with red on
socket- insert tightly.
Install Cable
Y
, match
Remove Cable
2
1
INSTALLING INTERIOR ASSEMBLY (F)
.
F
IMPORTANT:
If you need to disconnect
this cable, use a screw-
driver to hold down the
tab (marked red) before
carefully unplugging. DO
NOT FORCE as this may
result in damaging the
lock.
10
D
into the interior
