Step 6
Make sure you have prepared the door sensors for installation,
see step 3.
LOCK SENSOR (P)
Install on the interior side only. If necessary, trim tab from sensor
for doors with 2-3/8" (60mm) backset. Clean surface of door and
doorframe, remove film from adhesive, attach and secure close to
door edge as shown.
P
2-3/4"
(70mm)
2-3/8"
(60mm)
INSTALLING WIRED DOOR SENSOR
13
P
