Sun Microsystems GigabitEthernet FC-AL/P Combination Adapter Installation Manual page 63

PCI Edge Connector Pin Definitions (Bottom)
TABLE A-6
Pin Description
1 TRST#
2 +12V
3 TMS
4 TDI
5 +5V
6 INTA#
7 INTC#
8 +5V
9 RESERVED
10 VIO
11 RESERVED
12 KEYWAY
13 KEYWAY
14 RESERVED
15 RST#
16 VIO
17 GNT#
18 GND
19 RESERVED
20 AD30
21 +3.3V
22 AD28
23 AD26
24 GND
Pin Description Pin
25 AD24 49
26 IDSEL 50
27 +3.3V 51
28 AD22 52
29 AD20 53
30 GND 54
31 AD18 55
32 AD16 56
33 +3.3V 57
34 FRAME# 58
35 GND 59
36 TRDY# 60
37 GND 61
38 STOP# 62
39 +3.3V 63
40 SDONE 64
41 SBO# 65
42 GND 66
43 PAR 67
44 AD15 68
45 +3.3V 69
46 AD13 70
47 AD11 71
48 GND 72
Description Pin Description
AD09 73 AD[56]
KEYWAY 74 AD[54]
KEYWAY 75 VIO
C/BE[0]# 76 AD[52]
+3.3V 77 AD[50]
AD06 78 Ground
AD04 79 AD[48]
GND 80 AD[46]
AD02 81 Ground
AD00 82 AD[44]
VIO 83 AD[42]
REQ64# 84 VIO
+5V 85 AD[40]
+5V 86 AD[38]
Ground 87 Ground
C/BE[7]# 88 AD[36]
C/BE[5]# 89 AD[34]
VIO 90 Ground
PAR64 91 AD[32]
AD[62] 92 Reserved
Ground 93 Ground
AD[60] 94 Reserved
AD[58]
Ground
