A
A P P E N D I X
Specifications
This appendix displays the connectors and lists the following specifications for the
Sun GigabitEthernet FC-AL/P Combination adapter:
"Sun GigabitEthernet FC-AL/P Combination Adapter Connectors" on page 41
"Fibre Channel Interface Specifications" on page 42
"Performance Specifications" on page 42
"Power Requirements" on page 43
"Physical Dimensions" on page 43
"PCI Edge Connector Pin Definitions" on page 44
Sun GigabitEthernet FC-AL/P
Combination Adapter Connectors
FIGURE A-1
FIGURE A-1
displays the FC-AL and GigabitEthernet connectors of the adapter.
Sun GigabitEthernet FC-AL/P Combination Adapter Backplate
41
