FWA-3270A/B 1RU Network Application Platform
w ith x86 Based Intel® Xeon™ E3 Series and Gen
6 Core™ i7/i5/i3 Processor
Startup Manual
Packing List
Before you begin installing your card, please make sure
that the following items have been shipped:
• 1 x FWA-3270 Internet Security Platform
• 1 x Accessory Box
• 1 x Warranty Card
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note 1:
Acrobat Reader is required to view any PDF
file.Acrobat Reader can be downloaded at:
www.adobe.com/Products/acrobat/readstep2.
html (Acrobat is a trademark of Adobe)
Express Modules
• Express Module: Supports 4/8-port RJ-45 GE, 2-port SFP
GE, 2-port SFP 10GE, 4-port SFP GE and 4-port SFP
10GE
For a complete list of NMC support, please contact
Advantech.
• Dimensions (W x D): 72 x 172 mm
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our
support website at:
http://support.advantech.com
This manual is for the FWA-3270 Series.
Part No. 2002327010
Print in Taiwan
Specifications
Main Board Functions
• CPU: Intel®Xeon E3-1275/E3-1225/E3-1268LV5, Gen
6 Intel® Core™ i7-6700/i7-6700TE/i5-6500/i5-6500TE/
i3-6100/i3-6100TE, Intel® Pentium® processor G4400/
G4400TE, Intel® Celeron® G3900/G3900TE processor
• Chipset: Intel® C236/H110
• Memory: Supports dual channel DDR4 2133 MHz ECC
(only for Xeon® processor) or Non-ECC memory, up to
64 GB
• PCI-e Bus: 1xPCIe x8 gen.3, 2xPCIe x4 gen.2 for FH/HL
PCI-e card
• Network:
- NMC Module: 2 x NMC modules, support up to PCI-e
x8 gen.3 NMC module
- Management Interface: 2 x Intel I210-AT Gigabyte
Ethernet ports
• Mass Storage: 1 x 3.5 or 2 x 2.5"internal SATA HDD/SSD,
1 x mSATA/M.2 SSD, with transmission speed up to 6
GB/S
• Pripherials:
- LCD Module: 32 x 128 screen, with 5 buttons
- Console: 1 x RJ45 Console interface
- USB: 2 x USB3.0 connectors
- LAN: Supports up to 8 on-board Intel i210-AT
10/100/1000 Ethernet ports
- TPM: TPM2.0 (Infineon_SLB9635TT)
• IPMI: Optional
• Power Supply: 300 W, 3Y AC and DC redundent power
supply, 250W AC single power supply
• Dimensions (W x H x D):
430 x 44 x 550 mm / 430 x 44 x 375 mm
• Weight: 10 KG
• Environment: Operating
• Temperature: 0 ~ 40°C
• Humidity: 5 ~ 85% @ 40°C, 5 ~ 95% @ 40°C
1st Edition
July 2016
Non-operating
-20 ~ 60°C
(32 ~ 104°F)
(-4 ~ 140°F)
FWA-3270 Startup Manual 1
