  • Page 1 User Manual ASMB-610 ® ® LGA 1200 Intel Xeon W & 10th Gen. Core™ Proprietary Server Board with 4 x DDR4, 1 x PCIeX16, 2 x PCIeX4, 5 x USB 3.2, 3 x SATA 3, Quad LANs and IPMI...
  • Page 2 No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. The information provided in this manual is intended to be accurate and reliable.
  • Page 3 Discard used batteries according to the manufacturer's instructions. Ordering Information Part Number Chipset Memory IPMI Graphic DDR4 288-pin ECC/ ASMB-610-00A1 W480E AST 2600 Non-ECC unbuffered DIMM ASMB-610 User Manual...
  • Page 4 It should be free of marks and scratches and in perfect working order upon receipt. As you unpack the ASMB-610, check it for signs of ship- ping damage. (For example, damaged box, scratches, dents, etc.) If it is damaged or it fails to meet the specifications, notify our service department or your local sales representative immediately.

  • Page 5: Table Of Contents

    PCIe Expansion Slots ................23 2.13 Power Connector (ATXPWR1, ATX12V1, ATX12V3, ATX12V4, BP_P1) .. 2.14 SPI Flash Connector (SPI_CN1)............. 25 2.15 Low Pin Count Connector (LPC2)............26 2.16 PMBUS Connector (PMBUS1)..............27 2.17 M.2 Socket (M2_2280_1)................ 28 Chapter BIOS Operation........29 ASMB-610 User Manual...
  • Page 6 Figure 3.27Security configuration screen ........83 Figure 3.28HD Audio configuration screen......... 84 Security ....................85 Figure 3.29Security screen............85 3.5.1 Secure Boot ................86 Figure 3.30Secure boot screen ..........86 Boot......................88 Figure 3.31Boot screen .............. 88 ASMB-610 User Manual...
  • Page 7 B.12 Clear CMOS Connector (JCMOS1, JME1) ........... 114 Table B.12:Clear CMOS connector (JCMOS1, JME1) ..... 114 B.13 System I/O Ports ................... 115 Table B.13:System I/O ports............. 115 B.14 Interrupt Assignments ................115 Table B.14:Interrupt assignments ..........115 ASMB-610 User Manual...
  • Page 8 B.15 1st MB Memory Map................116 Table B.15:1st MB memory map ..........116 ASMB-610 User Manual viii...

  • Page 9: Chapter 1 Hardware Configuration

    Chapter Hardware Configuration...

  • Page 10: Introduction

    PCIe x4 slots (Gen3 x4 link). The PCIe x16 slot can also be two PCIe x8 slot with two Gen 3 x8 link, to fulfill multi-PCIe demands from video surveillance and factory auto- mation markets. In addition, ASMB-610 also comes with four Gigabit Ethernet LAN via dedicated PCIe bus, which offers bandwidth up to 500 MB/s eliminating network bottlenecks.

  • Page 11: Specifications

    1 x USB 3.2 internal header (2 ports). – 1 x USB 3.2 type A connector on board. LPC: One LPC connector supports Advantech TPM LPC modules.  GPIO: ASMB-610 supports 8-bit GPIO from super I/O for general purpose con-  trol applications. 1.3.5 Graphics Graphics processor: ASPEED AST2600.

  • Page 12: Ethernet Lan

     Humidity: 10% ~ 95% (Non condensing)  Power supply voltage: +3.3 V, +5 V, ±12 V, 5 V  Board size: MB only: 205 x 265 mm (8.07" x 10.43")  Weight: 1.5kg (packaging included)  ASMB-610 User Manual...

  • Page 13: Board Layout, Jumpers And Connectors

    Board Layout, Jumpers and Connectors Connectors on the ASMB-610 are linked to external devices such as hard disk drives. In addition, ASMB-610 has a number of jumpers that are used to configure the system for specific applications. The tables below list the functions of each jumper and connector. Later sections in this chapter give instructions for setting jumpers.
  • Page 14 LR Riser Card PCIeX16 link switch JPRSNT1 1-2 (default) between x16 or x8x8 PCIE SLOT SMBUS connector: to PCH JPSMB1 1-2 (default) (1-2)/to BMC (2-3) PCIE SLOT SMBUS connector: to PCH JPSMB2 1-2 (default) (1-2)/to BMC (2-3) PSON1 AT(1-2)/ATX(2-3) 2-3 (default) ASMB-610 User Manual...
  • Page 15 SYSFAN1 System FAN connector (4-pin) SYSFAN2 System FAN connector (4-pin) SYSFAN3 System FAN connector (4-pin) SYSFAN4 System FAN connector (4-pin) USB3_1 USB3.2 Gen 1 Port 5~6 (20-pin header) USB3_5 USB3.2 Gen 2 port 3 (Type A connector) ASMB-610 User Manual...

  • Page 16: Block Diagram

    Voltage - +12V/+5V/+5V_SB/+VCORE/+VDDQ/+VBAT TEMP. - CPU/MB Figure 1.3 Block diagram System Memory ASMB-610 has four 288-pin memory sockets for unbuffered ECC/Non-ECC 2933/ 2666/2400 MHz memory modules with maximum capacity of 128 GB (Maximum 32 GB for each DIMM). Note! ASMB-610 does NOT support registered DIMMs (RDIMMs).

  • Page 17: Safety Precautions

    Caution! There is a danger of a new battery exploding if it is incorrectly installed. Do not attempt to recharge, force open, or heat the battery. Replace the battery only with the same or equivalent type recommended by the man- ufacturer. Discard used batteries according to the manufacturer’s instructions. ASMB-610 User Manual...
  • Page 18 ASMB-610 User Manual...

  • Page 19: Chapter 2 Connecting Peripherals

    Chapter Connecting Peripherals...

  • Page 20: Introduction

    USB Ports (USB3_1_2, USB3_1, USB3_5) ASMB-610 provides 5 USB ports: USB3_12 is double-deck USB type A connector in rear IO, it represents USB3.2 Gen 2 port 1 and USB3.2 Gen 2 port 2.

  • Page 21: Vga Connector (Vga1)

    VGA Connector (VGA1) The ASMB-610 includes a VGA interface that can drive conventional CRT and LCD displays. VGA1 ASMB-610 User Manual...

  • Page 22: Serial Ports (Com1~2)

    Serial Ports (COM1~2) The ASMB-610 offers two serial ports, one is in rear (COM1) the other one is onboard header (COM2). The IRQ and address ranges for those ports are fixed. If you want to disable the port or change these parameters later, you can do this in the system BIOS setup.

  • Page 23: Lan Ports (Lan1_Lan2, Lan3_Lan4, Ipmi_Lan5)

    LAN Ports (LAN1_LAN2, LAN3_LAN4, IPMI_LAN5) The ASMB-622 is equipped with four GbE LAN (LAN1~4) ports and one dedicated IPMI LAN (LAN5) port. They are all with RJ-45 jacks and supported by all major net- work operating systems. IPMI_LAN5 LAN1_LAN2 LAN3_LAN4 ASMB-610 User Manual...

  • Page 24: External Keyboard & Mouse (Kbms1)

    There is an onboard external keyboard and mouse connector on the motherboard. This gives system integrators greater flexibility in designing their systems. A KBMS cable and cable bracket installed in the rear of system are provided as optional. (P/N: 1700019268-11, 1960063434N000) KBMS1   ASMB-610 User Manual...

  • Page 25: Cpu Fan Connector (Cpufan0)

    CPU Fan Connector (CPUFAN0) If a fan is used, this connector supports cooling fans that draw up to 3A (36W). CPUFAN0   ASMB-610 User Manual...

  • Page 26: System Fan Connector (Sysfan0 ~ Sysfan4)

    System FAN Connector (SYSFAN0 ~ SYSFAN4) If a fan is used, this connector supports cooling fans that draw up to 3A (36W). SYSFAN1~2 SYSFAN0 SYSFAN3~4   ASMB-610 User Manual...

  • Page 27: Front Panel Connector (Jfp1)

    Front Panel Connector (JFP1) Front Panel Connector is to connect will external switches and LEDs to monitor and control the ASMB-610. The front panel convert cable will pre-installed in HPC-61 series Chassis. JFP1 ASMB-610 User Manual...

  • Page 28: Atx Soft Power Switch (Pins 1, 3)

    System Suspend (S1, S3) Fast flash (1Hz) System Hibernation (S4) Slow flash (0.25Hz) System Off (S5) 2.9.4 Front Panel LAN Indicator (JFP1 Pins 5~8, 17~20) JFP1 pins 5, 6, 7, 8, 17, 18, 19 and 20 connect to LAN indicator. ASMB-610 User Manual...

  • Page 29: Case Open Connector (Jcase1)

    A chassis intrusion header is located at JCASE1 on the motherboard. Attach the appropriate cable from the chassis to be informed of a chassis intrusion when the chassis is opened. The default function is disabled and Pin 1-2 is bridged by a jumper cap. JCASE1   ASMB-610 User Manual...

  • Page 30: Serial Ata Interface (Sata0~2)

    2.11 Serial ATA Interface (SATA0~2) ASMB-610 features three high performance serial ATA III interfaces (up to 600 MB/s) for massive storage applications. Software RAID 0, 1, 10 & 5 can be supported with Intel RST (Rapid Storage Technology). SATA0 SATA1 SATA2  ...

  • Page 31: Pcie Expansion Slots

    2.12 PCIe Expansion Slots The ASMB-610 offers up to four expansion slots via Riser Cards. LR Riser Card con- nects with MB PCIEX16_SLOT1, it offers one PCIEX16 slot or two PCIEX8 slots comes from CPU. IR riser card connects with MB PCIEX4_SLOT2, MR riser card connect with MB PCIEX4_SLOT3, both of them offer one PCIEX4 slot that comes from PCH.

  • Page 32: Power Connector (Atxpwr1, Atx12V1, Atx12V3, Atx12V4, Bp_P1)

    ATX12V4 connect to GPU card to provide enough power to GPU card. One HDD Backplane power connectors BP_P1 provide enough power for the HDD Backplane. The on-board 4-pin connector connects to one HDD Backplane power connector on HDD backplane. BP_P1 ATXPWR1 ATX12V1 ATX12V3 ATX12V4 ASMB-610 User Manual...

  • Page 33: Spi Flash Connector (Spi_Cn1)

    2.14 SPI Flash Connector (SPI_CN1) SPI flash programmer pin header (for RMA) can flash BIOS while ASMB-610 is not powered on. SPI_CN1   ASMB-610 User Manual...

  • Page 34: Low Pin Count Connector (Lpc2)

    2.15 Low Pin Count Connector (LPC2) LPC2 connector is reserved for Advantech TPM module. (PN: PCA-TPM-00B1E) LPC2   ASMB-610 User Manual...

  • Page 35: Pmbus Connector (Pmbus1)

    2.16 PMBUS Connector (PMBUS1) PMBUS connector on ASMB-610 is reserved for communication with power supply via BMC. Note! Please remove the PMbus cable to avoid PMbus and DIMM conflict issue that may happen due to same address of SMbus, if the remote monitoring function with IPMI module is not used.

  • Page 36: Socket (M2_2280_1)

    2.17 M.2 Socket (M2_2280_1) ASMB-610 is equipped with one M.2 socket to support up to PCIe/SATA x 1 Mkey 2280 type storage devices. A screw to fasten the device is already installed on the nut. M2_2280_1 ASMB-610 User Manual...

  • Page 37: Chapter 3 Bios Operation

    Chapter BIOS Operation...

  • Page 38: Introduction

    The Setup program uses a number of menus for making changes and turning the special features on or off. This chapter describes the basic navigation of the ASMB-610 setup screens. Figure 3.1 Main setup screen AMI’s BIOS ROM has a built-in Setup program that allows users to modify the basic...

  • Page 39: Entering Bios Setup

    The right frame displays the key legend. Above the key legend is an area reserved for a text message. When an option is selected in the left frame, it is highlighted in white. Often a text message will accom- pany it. ASMB-610 User Manual...

  • Page 40: System Time/System Date

    MM/DD/YY format. The time must be entered in HH:MM:SS format. Advanced BIOS Features Setup Select the Advanced tab from the ASMB-610 setup screen to enter the Advanced BIOS setup screen. You can select any of the items in the left frame of the screen, such as CPU configuration, to go to the sub menu for that item.

  • Page 41: Platform Misc Configuration

    Figure 3.4 Platform misc configuration screen Native PCIE Enable  Enable/Disable PCIe native control. When changed to enable, 'Native ASPM' can be selected as 'Enabled' for OS control and ASPM or 'Disabled' for BIOS control. Default is disable for BIOS control. ASMB-610 User Manual...

  • Page 42: Cpu Configuration

    3.3.2 CPU Configuration Figure 3.5 CPU configuration screen   Hardware Prefetcher  Turns on/off the MLC streamer prefetcher. Hardware Prefetcher is a technique that fetches instructions and/or data from memory into the CPU cache memory ASMB-610 User Manual...
  • Page 43 When enabled through the BIOS, two 64-byte cache lines are fetched into a 128-byte sector, regardless of whether the additional cache line has been requested or not. You may choose to enable or disable it. ASMB-610 User Manual...
  • Page 44 This feature is used to enable or disable the Intel Virtualization Technology (IVT) extension. It allows multiple operating systems to run simultaneously on the same system. It does this by creating virtual machines, each running its own x86 operating system. ASMB-610 User Manual...
  • Page 45 Active Processor Cores  Number of cores to enable in each processor package. Hyper-Threading  Enable or disable a Hyper-Threading processor to optimize as two logical pro- cessors, allowing the OS to schedule two threads or processors simultaneously. ASMB-610 User Manual...

  • Page 46: Power & Performance

     This item enables or disables CPU advanced encryption standard instructions. 3.3.3 Power & Performance Figure 3.6 CPU - power management control screen ASMB-610 User Manual...
  • Page 47 Boot performance mode  Select the performance state that the BIOS will set before OS handoff.   Intel (R) SpeedStep (tm)  Allows more than two frequency ranges to be supported. ASMB-610 User Manual...
  • Page 48 Turbo Mode  Enable/Disable processor turbo mode. (requires Intel Speed Step or Intel Speed Shift to be available and enabled.) C States  Enable/Disable CPU power management. Allows CPU to go to C states when not 100% utilized. ASMB-610 User Manual...

  • Page 49: Pch-Fw Configuration

    3.3.4 PCH-FW Configuration This page shows the Intel ME configuration. Figure 3.7 PCH-FW configuration screen Me FW Image Re-Flash  Enable/Disable Me FW image re-flash function. ASMB-610 User Manual...

  • Page 50: Trusted Computing

    3.3.5 Trusted Computing Figure 3.8 TPM settings screen Security Device Support  Enable or disable TPM support. You can purchase Advantech LPC TPM module to enable TPM function. Disable Block Sid  Enable or Disable Block Sid. Default is disable.

  • Page 51: Acpi Settings

    ACPI Sleep State  Specifies the ACPI sleep state when the system enters suspend. S3 Video Repost  Enable or disable S3 video repost. Note! USB3_1_2 (USB port1 and port2 on IO Board) cannot support ACPI Sleep State.   ASMB-610 User Manual...

  • Page 52: Smart Settings

    3.3.7 SMART Settings Figure 3.10 SMART settings screen SMART Self Test  Enable or disable SMART self-test on all HDDs during post. ASMB-610 User Manual...

  • Page 53: Super Io Configuration

    3.3.8 Super IO Configuration Figure 3.11 Super IO configuration screen COM 1 Configuration  – Serial Port Enable or disable Serial Port (COM1). – Change Settings Select an optimal setting for Super IO Device. ASMB-610 User Manual...
  • Page 54   ASMB-610 User Manual...
  • Page 55 COM 2 Configuration  – Serial Port Enable or disable Serial Port (COM2). – Change Settings Select an optimal setting for Super IO Device. ASMB-610 User Manual...

  • Page 56: Nct6776 Hw Monitor

    3.3.9 NCT6776 HW Monitor Figure 3.12 PC health status screen CPU Warning Temperature  Use this to set the CPU warning temperature threshold. When the system reaches the warning temperature, the speaker will beep. ASMB-610 User Manual...
  • Page 57 ACPI Shutdown Temperature  Use this to set the ACPI shutdown temperature threshold. When the system reaches the shutdown temperature, it will be automatically shut down by ACPI OS to protect the system from overheat damage. ASMB-610 User Manual...
  • Page 58 Make sure your board is paired with the chassis kit correctly to run this function. Watch Dog Timer  Enable/Disable Watch Dog Timer function. ASMB-610 User Manual...
  • Page 59 Smart Fan Function  ASMB-610 offers two different fan modes: 1.Normal Mode - Enable smart fan for normal system configuration. 2.Disable - All fans run at full speed. ASMB-610 User Manual...

  • Page 60: S5 Rtc Wake Settings

    3.3.10 S5 RTC Wake Settings Figure 3.13 Wake system setting Wake system from S5  Enable or disable system wake on alarm event. When enabled, system will wake on the hr:min:sec specified. ASMB-610 User Manual...

  • Page 61: Serial Port Console Redirection

    3.3.11 Serial Port Console Redirection Figure 3.14 Serial port console redirection screen 3.3.11.1 Console Redirection Console Redirection  Enable or disable the console redirection feature. ASMB-610 User Manual...
  • Page 62 3.3.11.2 Serial Communication via IPMI COM Console Redirection  Enable or disable the console redirection feature. ASMB-610 User Manual...
  • Page 63 On Legacy OS, the Number of Rows and Columns supported redirection. Redirect After POST  When 'Bootloader' is selected, then Legacy Console Redirection is disabled before booting to legacy OS. When 'Always Enable' is selected, then Legacy Console Redirection is enabled for legacy OS. ASMB-610 User Manual...

  • Page 64: Intel Txt Information

    3.3.12 Intel TXT Information Figure 3.15 Intel TXT information screen ASMB-610 User Manual...

  • Page 65: Usb Configuration

    XHCI Hand-off  This is a workaround for OS without XHCI hand-off support. The XHCI owner- ship change should be claimed by XHCI driver. USB Mass Storage Driver Support  Enable or disable USB Mass Storage Driver Support. ASMB-610 User Manual...
  • Page 66   USB transfer time-out  The time-out value for Control, Bulk, and Interrupt transfers. Device reset time-out  USB mass storage device Start Unit command time-out. ASMB-610 User Manual...
  • Page 67 Maximum time the device will take before it properly reports itself to the Host Controller. 'Auto' uses default value: for a Root port it is 100ms, for a Hub port the delay is taken from Hub descriptor. ASMB-610 User Manual...
  • Page 68 Mass Storage Devices  Mass storage device emulation type. 'Auto' enumerates devices according to their media format. Optical drives are emulated as 'CDROM', drives with no media will be emulated according to a drive type. ASMB-610 User Manual...

  • Page 69: Network Stack Configuration

    3.3.14 Network Stack Configuration Figure 3.17 UEFI network stack configuration screen ASMB-610 User Manual...
  • Page 70 PXE boot wait time  Wait time in seconds to press ESC key to abort the PXE boot. Media detect count  Number of times the presence of media will be checked. ASMB-610 User Manual...

  • Page 71: Csm Configuration

    3.3.15 CSM Configuration Figure 3.18 CSM configuration screen CSM Support  Enable or disable CSM (Compatibility Support Module) configuration support. When disabled, the system can only support UEFI mode. ASMB-610 User Manual...
  • Page 72  This items is useful when RT code is executed above 1MB. When it's set as ‘Upon Request’, GA20 can be disabled using BIOS services. When it's set as ‘Always’, it does not allow disabling of GA20. ASMB-610 User Manual...
  • Page 73 INT19 Trap Response  BIOS reaction on INT19 trapping by Option ROM. When it's set as ‘Immediate’, the trap will be executed right away. When it's set as ‘Postponed’, the trap will be executed during legacy boot. ASMB-610 User Manual...
  • Page 74 HDD Connection Order  Some OS require HDD handles to be adjusted. Boot option filter  This option controls Legacy/UEFI ROMs priority. ASMB-610 User Manual...
  • Page 75 Controls the execution of UEFI and Legacy Storage OpROM. Video  Controls the execution of UEFI and Legacy Video OpROM. Other PCI devices  Determines execution of OpROM policy for devices other than Network, Storage or Video. ASMB-610 User Manual...

  • Page 76: Nvme Configuration

    3.3.16 NVMe Configuration Figure 3.19 NVMe configuration Self Test Option  123. ASMB-610 User Manual...

  • Page 77: Iscsi Configuration

    Self Test Action  123. 3.3.17 iSCSI Configuration Figure 3.20 iSCSI configuration ASMB-610 User Manual...

  • Page 78: Chipset

    Chipset Figure 3.21 Chipset screen ASMB-610 User Manual...

  • Page 79: System Agent (Sa) Configuration

    Above 4G MMIO BIOS assignment  Enable or disable above 4GB Memory Mapped IO BIOS assignment. This is dis- abled automatically when the size is set to 2048MB. Please set “Disabled” when installing VMWare under CSM Disabled. ASMB-610 User Manual...
  • Page 80 Maximum Memory Frequency selections in Mhz. Valid values should match the refclk, e.g, divide by 133 or 100. Max TOLUD  Maximum Value of TOLUD. Dynamic assignment would adjust TOLUD automat- ically based on largest MMIO length of installed add-on cards. ASMB-610 User Manual...

  • Page 81: Graphics Configuration

    3.4.2 Graphics Configuration Primary Display  Select Auto/IGFX/PEG/PCI Graphics device as primary display. Internal Graphics  Keep IGFX enabled based on the setup options. ASMB-610 User Manual...
  • Page 82 3.4.2.1 PEG Port Configuration PCIX16 SLOT1 (LR RISER SLOT1)  Enable Root Port: Auto/Disabled/Enabled. Max Link Speed: Configure Max Speed for PCIX16 SLOT1 (LR RISER SLOT1). PCIX16 SLOT1 (LR RISER SLOT2)  Enable Root Port: Auto/Disabled/Enabled. ASMB-610 User Manual...
  • Page 83 Max Link Speed: Configure Max Speed for PCIEX16 SLOT1 (LR RISER SLOT2). PEG Port Feature Configuration  Detect Non-Compliance PCI Express Device in PEG. ASMB-610 User Manual...

  • Page 84: Pch-Io Configuration

    30 seconds to power on after a power failure. On the other hand, the system will auto power on if power is restored within 30 seconds, before 5VSB actually drops, even if “Restore AC Power Loss” is set to “power off”.   ASMB-610 User Manual...
  • Page 85 3.4.3.1 PCI Express Configuration Figure 3.24 PCI Express configuration screen BMC Graphic  Enable or disable onboard BMC Graphic. ASMB-610 User Manual...
  • Page 86 M.2 SLOT  Enable or disable onboard M.2 SLOT. PCIe Speed  Configuration speed for M.2 SLOT. ASMB-610 User Manual...
  • Page 87 IR RISER SLOT  Enable or disable PCI Express slots on IR RISER Card. (IR RISER Card installed on MB PCIEX4_SLOT2) PCIe Speed  Sets PCIe speed for PCI Express slots on IR RISER Card. ASMB-610 User Manual...
  • Page 88 MR RISER SLOT  Enable or disable PCI Express slots on MR RISER Card. (IR RISER Card installed on MB PCIEX4_SLOT3) PCIe Speed  Sets PCIe speed for PCI Express slots on MR RISER Card. ASMB-610 User Manual...
  • Page 89 If enabled for any ports, Staggered Spin Up will be performed and only the drives which have this option enabled will spin up at boot. Otherwise all drives spin up at boot. SATA Device Type  Identifies the SATA port is connected to Solid State Drive or Hard Disk Drive. ASMB-610 User Manual...
  • Page 90 Change to enabled for Compliance Mode testing. USB 3.0 port 1~6, USB 2.0 port 1~13  Enable/Disable this USB physical connector (physical port). Once disabled, any USB devices plug into the connector will not be detected by BIOS or OS. ASMB-610 User Manual...
  • Page 91 Enable/disable the PCH BIOS Lock Enable feature. This item must be enabled to ensure SMM protection of flash. Force unlock on all GPIO pads  If enabled, the BIOS will force all GPIO pads to be in an unlocked state. ASMB-610 User Manual...
  • Page 92 3.4.3.5 HD Audio Configuration Figure 3.28 HD Audio configuration screen HD Audio  Controls detection of the HD-Audio device. ASMB-610 User Manual...

  • Page 93: Security

    Security Select Security Setup from the ASMB-610 setup main BIOS setup menu. All Security Setup options, such as password protection and secure boot are described in this section. To access the sub menu for the following items, select the item and press <Enter>.

  • Page 94: Secure Boot

     Secure Boot feature is active if Secure Boot is Enabled. Platform Key (PK) is enrolled and the System is in User mode. The mode change requires platform reset. Secure Boot Mode  Secure Boot mode options. ASMB-610 User Manual...
  • Page 95 Restore Factory Keys  Force the system to user mode. Key Management  Enables expert users to modify Secure Boot Policy variables without full authen- tication. ASMB-610 User Manual...

  • Page 96: Boot

    Enabled, an OEM logo is shown instead of POST messages. Boot Option Priorities  Choose boot priority from boot device. Note! UEFI devices can be recognized as default. Set 'Enabled' in CSM Con- figuration to support legacy devices when needed. ASMB-610 User Manual...

  • Page 97: Save & Exit

    Restore Defaults  Select this option to restore BIOS configuration as original. Save as User Defaults  Select this option to save user's configuration. Restore User Defaults  Select this option to restore BIOS to user's configuration. ASMB-610 User Manual...

  • Page 98: Server Mgmt

    When you make some critical changes, the system will still reboot even after you choose 'Save Changes and Exit'. Server Mgmt Figure 3.33 Server Mgmt screen BMC Support  Enable or disable interfaces to communicate with BMC. ASMB-610 User Manual...
  • Page 99 Wait for BMC response for specified time out. BMC starts at the same time when BIOS starts during AC power ON. It takes around 30 seconds to initialize Host to BMC interfaces with beep sound but without display output until initial- ization is completed. BMC Counter  ASMB-610 User Manual...
  • Page 100 Enter values between 5 to 20 min for OS Wtd Timer Expiration value. OS Wtd Timer policy  Configure how the system should respond if the OS Wtd Timer expires. Not available if OS Wtd Timer is disabled. ASMB-610 User Manual...

  • Page 101: System Event Log

    Choose options for reactions to a full SEL. Options: Do Nothing/Erase Immedi- ately/Delete oldest record. Log EFI Status Codes  Disable the logging of EFI status codes or log only error code or progress code or both. ASMB-610 User Manual...

  • Page 102: Bmc Self Test Log

    BMC Self Test Log Figure 3.35 BMC self test log Erase Log  Erase log or not on every reset. When Log is Full  Clear log or do not log any more when log is full. ASMB-610 User Manual...

  • Page 103: Bmc Network Configuration

     Select to configure LAN channel1 parameters statically or dynamically (by BIOS or BMC). Unspecified option will not modify any BMC network parameters during BIOS phase. ASMB-610 design has reserved LAN5 port as IPMI dedi- cated NIC. ASMB-610 User Manual...
  • Page 104 ASMB-610 User Manual...

  • Page 105: Chapter 4 Driver Installation

    Chapter Driver Installation...

  • Page 106: Before You Begin

    Before You Begin To ensure drivers are the most up-to-date, they are downloadable from Advantech's support website for ASMB-610 at: https://www.advantech.tw/search/?q=ASMB- 610&st=support Before you begin, it is important to note that most display drivers need to have the relevant software application already installed in the system prior to installing the enhanced display drivers.

  • Page 107: Lan

    4.2.3 The ASMB-610 has four Gigabit Ethernet LAN connections via dedicated PCI Express x4 lanes: GbE LAN1~4 via Intel I350 that offer bandwidth of up to 500 MB/ sec, eliminating the bottleneck of network data flow and incorporating Gigabit Ether- net at 1000 Mbps.
  • Page 108 ASMB-610 User Manual...

  • Page 109: Programming The Watchdog Timer101

    Appendix Programming the Watchdog Timer...

  • Page 110: Watchdog Timer Overview

    The ASMB-610’s watchdog timer can be used to monitor system software operation and take corrective action if the software fails to function within the programmed period. This section describes the operation of the watchdog timer and how to pro- gram it.
  • Page 111 Unlock NCT6776 Select register of watchdog timer Enable the function of the watchdog timer Use the function of the watchdog timer Lock NCT6776 ASMB-610 User Manual...
  • Page 112 Bit 5: Write 1 to generate a timeout signal immediately and auto- write matically return to 0. [default=0] Bit 4: Read status of watchdog timer, 1 means timer is “timeout”. AA (hex) Write this address to I/O port 2E (hex) to lock NCT6776. ASMB-610 User Manual...

  • Page 113: Example Programs

    Mov al,10; 10 minutes Out dx,al ;----------------------------------------------------------- Dec dx ; lock NCT6776 Mov al,0aah Out dx,al Enable watchdog timer and set 5 minutes as the timeout interval ;----------------------------------------------------------- Mov dx,2eh ; unlock NCT6776 Mov al,87h Out dx,al ASMB-610 User Manual...
  • Page 114 Out dx,al Enable watchdog timer to be reset by mouse ;----------------------------------------------------------- Mov dx,2eh ; unlock NCT6776 Mov al,87h Out dx,al Out dx,al ;----------------------------------------------------------- Mov al,07h ; Select registers of watchdog timer Out dx,al Inc dx Mov al,08h ASMB-610 User Manual...
  • Page 115 Dec dx ; Enable the function of watchdog timer Mov al,30h Out dx,al Inc dx Mov al,01h Out dx,al ;----------------------------------------------------------- Dec dx ; Enable watchdog timer to be strobed reset by keyboard Mov al,0f7h Out dx,al Inc dx ASMB-610 User Manual...
  • Page 116 Dec dx ; Generate a time-out signal Mov al,0f7h Out dx,al ;Write 1 to bit 5 of F7 register Inc dx In al,dx Or al,20h Out dx,al ;----------------------------------------------------------- Dec dx ; lock NCT6776 Mov al,0aah Out dx,al ASMB-610 User Manual...

  • Page 117: Appendix B I/O Pin Assignments

    Appendix I/O Pin Assignments...

  • Page 118: Usb 3.2 Header (Usb3_1)

    Table B.1: USB 3.1 header (USB5_6) Signal Signal +5V_USB USB3_RX_D1- +5V_USB USB3_RX_D1+ USB3_RX_D2- USB3_RX_D2+ USB3_TX_D1- USB3_TX_D1+ USB3_TX_D2- USB3_TX_D2+ USB2_D1- USB2_D1+ USB2_D2- USB_OC USB2_D2+ VGA Connector (VGA1) Table B.2: VGA connector (VGA1) Signal Signal GREEN BLUE H-SYNC V-SYNC ASMB-610 User Manual...

  • Page 119: Interface (Com2)

    RS-232 Interface (COM2) Table B.3: RS-232 interface (COM2) COM1/COM2 Signal LAN Ports (LAN1~LAN4, IPMI LAN5) Table B.4: LAN RJ-45 port (LAN1~2, LAN3_4, LAN5) Signal Signal MID0+ MID2+ MID0- MID2- MID1+ MID3+ MID1- MID3- ASMB-610 User Manual...

  • Page 120: External Keyboard And Mouse Connector (Kbms1)

    Table B.5: External keyboard and mouse connector (KBMS1) Signal KB CLK KB DATA MS DATA MS CLK System Fan Power Connector (SYSFAN0~4) Table B.6: Fan power connector (SYSFAN0~4) Signal +12 V DETECT Case Open Connector (JCASE1) Table B.7: Case open connector (JCASE1) Signal CASEOP ASMB-610 User Manual...

  • Page 121: Spi Flash Card Pin Connector (Spi_Cn1)

    Table B.8: SPI flash connector (SPI_CN1) Signal Signal SPI_CS# SPI_CLK SPI_MISO SPI_MOSI SMBUS Connector (SMBUS1) Table B.9: SMBUS connector (SMBUS1) Signal Clock Data B.10 PMBUS Connector (PMBUS1) Table B.10: PMBUS connector (PMBUS1) Signal SMB_SCL_PM SMB_SDA_PM SMB_ALT_PM +3.3V ASMB-610 User Manual...

  • Page 122: Lpc Connector (Lpc2)

    Table B.11: LPC connector (LPC2) Signal Signal CLK_24M_LPCCN LPC_AD1 PLTRST_LPC LPC_AD0 LPC_FRAME +3.3V LPC_AD3 LPC_AD2 SMB_SCL_LPC SERIRQ_PCH SMB_SDA_LPC +5V_AUX B.12 Clear CMOS Connector (JCMOS1, JME1) Table B.12: Clear CMOS connector (JCMOS1, JME1) JCMOS1 JME1 Signal Signal RTC_RST_PCH HDA_SDOUT_PCH +3.3V_AUX ASMB-610 User Manual...

  • Page 123: System I/O Ports

    Intel 8 series/C226 Chipset Family SMBus Controller IRQ11 Available IRQ12 PS/2mouse IRQ13 Numeric data processor IRQ14 Available IRQ15 Available IRQ3 Serial communication port 2 IRQ4 Serial communication port 1 IRQ5 Available IRQ6 Available IRQ7 Parallel port 1 (print port) ASMB-610 User Manual...
  • Page 124 1st MB Memory Map Table B.15: 1st MB memory map Addr. range (Hex) Device E0000h - FFFFFh BIOS D0000h - DFFFFh Unused C0000h - CFFFFh VGA BIOS A0000h - BFFFFh Video Memory 00000h - 9FFFFh Base memory ASMB-610 User Manual...
  • Page 125 ASMB-610 User Manual...
  • Page 126 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2022...

Table of Contents
