FWA-3700 User manual
Rackmount Internet Security Platform with 4 GbE Front LAN Ports and 1 FE
10/100 manager port / 1 mini PCI Expansion Slots/ LCD Display
Advantech Internet Security Platform
Copyright Notice
This document is copyrighted, 2006. All rights are reserved. The original manufacturer
reserves the right to make improvements to the products described in this manual at
any time without notice. No part of this manual may be reproduced, copied, translated
or transmitted in any form or by any means without the prior written permission of the
original manufacturer. Information provided in this manual is intended to be accurate
and reliable. However, the original manufacturer assumes no responsibility for its use,
nor for any infringements upon the rights of third parties which may result from its use.
CE Notification
The FWA-3700, developed by Advantech Co., Ltd., has passed the CE test for
environment specifications when shielded cables are used for external wiring. We
Advertisement
Table of Contents
Related Manuals for Advantech FWA-3700
Summary of Contents for Advantech FWA-3700
- Page 1 CE Notification The FWA-3700, developed by Advantech Co., Ltd., has passed the CE test for environment specifications when shielded cables are used for external wiring. We...
- Page 2 1st Edition Printed in Taiwan March 2006 Product warranty Advantech warrants to you, the original purchaser, that each of its products will be free from defects in materials and workmanship for two year from the date of purchase. This warranty does not apply to any products which have been repaired or altered by persons other than repair personnel authorized by Advantech, or which have been subject to misuse, abuse, accident or improper installation.
- Page 3 One CD-ROM for user manual (PDF file) If any of these items are missing or damaged, contact your distributor or sales representative immediately. Technical Support and Sales Assistance If you have any technical questions about the FWA-3700 or any other Advantech products, please visit our support website at: http://www.advantech.com.tw/support http://www.advantech.com.
-
Page 4: Table Of Contents
2.4 Installing Hard Drive................10 2.5 Installing Compact Flash...........11 2.6 Setting LAN Bypass function............12 Appendix A...........15 A.1 NAME-3700 Mother Board..........16 Figures Figure 1-1: FWA-3700 dimensions..............4Figure 1-2: Outlook of FWA-3700................. 4 Figure 2-1: Front view FWA-3700............7Figure 2-2: Removing cover............. 7Figure... - Page 5 1.1 Introduction Conceived as a powerful but low power consumption rack-mount Internet security platform, the FWA-3700 was specifically designed for mainstream IDS/IPS, Anti-virus, VPN gateway and Unified Threat Management (UTM) applications. Using the latest Intel Pentium M processor combined with the Mobile Intel 915GM Express chipset and Intel ICH6M I/O Controller Hub, the FWA-3700 provides unprecedented performance, connectivity and throughput without compromising on system thermal design.
-
Page 6: Dimensions
Chipset: Intel 915GM, ICH6M BIOS: Award 4 Mb Flash Memory: Support DDR2 533/400, Max. Capacity 2 GB, Socket 200-pin SOD DIMM x 2 Ethernet: 1 10/100 Fast Ethernet & 4 10/100/1000 Gigabit Ethernet, RJ-45 x Drive Bay: 3.5”HDD x1 Management: Console RS-232 x1 Cooling: Fan (15 CFM) x2, Blower x1 Miscellaneous: Power Switch, 2 LED indicators for Power/HDD, CompactFlash Socket x1, LCD Display Module x1... -
Page 7: Model List
Before you begin, you should also gather together all of the device you plan to install, as well as the CPU, RAM, HDD, and etc. The front panel of FWA-3700 includes a LCD display module, four Ethernet ports, aRS-232 console port, and two LEDs where one is power LED and another is HDD LED. -
Page 8: Removing The Cover
1 Mgnt, 4 GbE Lan LCM module Figure 2-1: Front view of FWA-3700 2.1 Removing the cover There are screws which secure the cover to the chassis. They are along the sides, near the top. Remove them, and then slide the cover to the rear of the chassis. -
Page 9: Installing Central Processing Unit (Cpu)
2.2 Installing Central Processing Unit (CPU) Locate the 479-pin CPU ZIF socket on the motherboard. And unlock the Socket actuation to the left side directly. Position the CPU above the socket that its marked corner (golden cut edge on the CPU upper corner) matches the base of the socket lever. Insert the CPU into the socket. - Page 10 Figure 2-5: Install RAM module 2.4 Installing Hard Disk Drive Unscrew each side of the HDD supporting frame on the chassis and pull it out. Put the HDD above the HDD supporting frame and position the screws accordingly. Screw each side of the HDD supporting frame to fix on the chassis. Connect the SATA cable included in the accessory box to the connector on the HDD.
-
Page 11: Installing Compact Flash
Figure 2-7: Install CF card Setting LAN Bypass function FWA-3700 provides LAN Bypass function showed as Figure 2-8. When system shuts down, LAN1-LAN2 will connect directly to avoid network broken. The jump "J3 & CNRL1-2" allows you to set LAN Bypass function. (See J4 pins... - Page 12 When jumper keeps on pins 4-6, follow below steps to set LAN Bypass function via BIOS. Turn on FWA-3700 platform. Then hold down the <Delete> key during the boot process to enter BIOS menu. Move to "LAN Bypass Control" Item Press <PageUp>...
-
Page 13: Name-3700 Mother Board
Pin Assignments APPENDIX A.1 NAME-3700 Mother Board JCMOS1 CNRL1... - Page 14 Jumper setting of FWA-3700:...
