- Page 1 Startup Manual FPM-D Series FPM-D12T-RE, FPM-D15T-RE, FPM-D17T-RE...
-
Page 2: Table Of Contents
Table of Contents Chapter 1 Install FPM and TPC products ... 1 Confirm your TPC and FPM Products ............2 FPM 12” Products and TPC ............. FPM 15” & Above Products and TPC Installation ........7 Chapter 2 LED Status Indicator ......8 LED status indicator light on the FPM display ......... -
Page 3: Install Fpm And Tpc Products
Chapter Install FPM and TPC products TPC-B300 使用手冊... -
Page 4: Confirm Your Tpc And Fpm Products
Confirm your TPC and FPM Products FPM products are equipped with positioning pillars for the convenience of user instal- lation, allowing customers to confirm the correct installation position before securing with a screwdriver. However, due to differences between the TPC-B600 series and other series such as TPC-B200, TPC-B300, TPC-B500, etc., customers may need to manually adjust. - Page 5 Secure TPC and FPM 12” 1.2.2 Use the screws provided in the accessory box to securely attach your FPM and TPC products. In Picture 1.2 ,1.3 and 1.4, the red guide lines indicate the positions of the five screws used for fastening FPM and TPC Picture 1.2 TPC-B300 Installation Picture 1.3 TPC-B510 Installation TPC-B300 使用手冊...
- Page 6 Picture 1.4 TPC-B520 Installation FPM 15” & Above Products and TPC Installation FPM 15” & Above Positioning Pillars 1.3.1 If the FPM you purchased is larger than 15" and is paired with TPC products from the TPC- B200/B300/B500 series, the default positioning pillars of FPM do not need to be changed. However, if you are switching from the TPC-B600 series to another series, you need to confirm whether the positioning pillar positions match those marked in red boxes as shown in Picture 1.4.
- Page 7 as shown in Picture 1.5. Use a Phillips screwdriver to unscrew the positioning pillars coun- terclockwise, and then reposition them in the correct locations. Please refer to Picture 1.5, where the positioning pillars have already been moved to the correct positions. Picture 1.5 FPM-D15X &...
- Page 8 Picture 1.7 TPC-B510 Installation Picture 1.8 TPC-B520 Installation TPC-B300 使用手冊...
-
Page 9: Fpm 15" & Above Products And Tpc Installation
Picture 1.9 TPC-B610 Installation 1.3.3 Touch Driver Installation & Calibration Use the screws provided in the accessory box to securely attach your FPM and TPC products. In Picture 1.6, 1.7, 1.8, and 1.9 the red guide lines indicate the positions of the five screws used for fastening FP TPC-B300 使用手冊... -
Page 10: Led Status Indicator
Chapter LED Status Indicator TPC-B300 使用手冊... -
Page 11: Led Status Indicator Light On The Fpm Display
LED status indicator light on the FPM display Table 2.1: LED Indicators Indicator Default Status (ErP Enable) Status 2 (ErP Disable) Green Normal Powered-On State Normal Powered-On State Orange Sleep (S3)/Hibernate (S4) Sleep (S3)/Hibernate (S4)/Shutdown(S5) Shutdown(S5)/Power Off Power Off TPC-B300 使用手冊... -
Page 12: Panel Mount Installation
Chapter Panel Mount Installation TPC-B300 使用手冊... -
Page 13: Panel Mount Installation
Panel Mount Installation Before installing the TPC panel computer into the panel opening, ensure that the adhesive waterproof gasket on the front bezel is correctly positioned. Ensuring adequate air circulation with a required clearance on all sides. Refer to the diagram for the minimum clearance (100mm), air inlet and outlet directions (blue arrows), and a suggested mounting panel thickness of less than 6mm (0.236"). - Page 14 Take out the panel mounting kits from the accessory box and attach them to the fixed holes around the chassis. Tighten the screw of each fastening button into position to clamp and secure the panel. Insert the screws into each bracket and tighten them to secure the brackets in place.
- Page 15 It is recommended to install the panel with a thickness less than 6 millimeters (0.236 inches). Picture 3.3 Panel Mounting Kit Installation Picture 3.4 Tighten with screw driver TPC-B300 使用手冊 TPC-B300 使用手冊...
-
Page 16: Driver Installation & Calibration
Chapter Touch Driver Installation & Calibration TPC-B300 使用手冊... -
Page 17: Resistive Touch Driver Installation
Please click the OK button and perform device driver uninstallation before proceeding. 1. Download resistive driver from Advantech Website, please search for your FPM- DXXT-RE model name. 2. Run Setup.exe program. - Page 18 5. Starting from PenMount Universal Driver V2.4, the setup program will allow users to choose to install the device as a “Mouse Device” or “Digitizer Device” on systems that support Digitizers. A message box will pop up. 6. Please select “Yes” for installing PenMount as mouse mode. 7.
-
Page 19: Resistive Touch Calibration
Resistive Touch Calibration For resistive touch screens, the most important feature that the PenMount Control Panel provides is calibration. This feature is disabled for projected capacitive touch screens, since they usually do not need calibration. 1. Click on “Taskbar”, and then select PenMount Control Panel as shown: 2. - Page 20 4. The Standard calibration function uses four points for calibration and one point for confirmation. Under normal circumstances, standard calibration is all you need to perform an accurate calibration. 5. For better calibration results, please use a stylus and press on the red dot until the program prompts “Lift off to proceed”.
- Page 21 使用前請檢查核實產品的規格。本手冊僅作為參考。 產品規格如有變更，恕不另行通知。 未經研華股份有限公司書面許可，本手冊中的所有內容不得通過任何途徑以任何形式複 製、翻印、翻譯或者傳輸。 所有的產品品牌及產品型號均為各公司之註冊商標。 © Advantech Co., Ltd. 2023 TPC-B300 使用手冊...
