Advantech FWA-6480 Startup Manual

FWA-6480 Security Platform
2U Rackmount Intel
processor, Intel
with 8 Gigabit Ethernet Ports & LCD Display
Startup Manual
Packing List
Before installation, please make sure that the following
items have been received:
1. One FWA-6480 Security Platform
2. One warranty certificate
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note: Acrobat Reader is required to view any PDF
file. Acrobat Reader can be downloaded at:
www.adobe.com/Products/acrobat/readstep2.
html (Acrobat is a trademark of Adobe)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com.tw/support
http://www.advantech.com
For technical support and service, please visit our
support website at:
http://service.advantech.com.tw/support
This manual is for the FWA-6480 series, Rev. A.
Part No. 2002648001
Printed in China
Arrow.com.
Downloaded from
Dual Xeon
®
5100P Platform
®
2nd Edition,
June 2009
Dual/Quad Core
®
Specifications
Standard PC functions
• CPU: 2 x Intel Dual-Core 5100/5200 series processors or
2 x Intel Quad-Core 5300/5400 series processors
• System Bus: FSB 1066/1333MHz
• System Chipsets: Intel 5100P (San Clemente) + ICH9R
• Memory: DDR2 533/667 MHz ECC registered. Up to
16GB with 4 DIMMs, 4G dual rank memory module.
• Bus:
- 2 x PCI-E x8 connector to IO board
- 1 x PCI-E x4 connector to IO board
- 1 x PCI-E x8 slot for riser card
• Ethernet:
Management port 1 x Intel 82573E GbE controller sup-
port 10/100 Ethernet for management
Interface 4 x 10/100/1000 Mbps via RJ-45 in-
terface and 4 x GbE via SFP interface
from Intel 82571 GbE controllers
LAN Bypass 2 segments LAN bypass
• Storage:
- 2 x 3.5" SATA HDD docks
- 1 x CompactFlash socket
• Peripherals:
USB 2 x USB 2.0 ports on front panel
Serial 1 x front console port RJ-45
LCD Module 1
• Dimensions (W x H x D): 430 x 88 x 515 mm
(16.9" x 3.5" x 20.3")
• Weight: 18 kg (40 lb)
Operating
• Environment:
0~40° C
• Temperature:
(32~104° F)
5~85% @ 40° C
• Humidity:
FWA-6480 Startup Manual
Non-operating
-20~75° C
(-4~167° F)
5~95%
(104° F)
