Industrial Grade Cyber Security Appliance based on
Intel® Atom™ x5-E3940/ x5-E3930 Processor Platform
Startup Manual
Packing List
Before installation, ensure that the following materials have
been received:
• One FWA-1211 din-rail Platform
• One box of accessories
• One warranty certificate
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note 1: Acrobat Reader is required to view any PDF file
Acrobat Reader can be downloaded at: www.
adobe.com/Products/acrobat/readstep2.html
(Acrobat is a trademark of Adobe).
Note 2: Supplied by certified power supply:
FSP040-RHAN2
ADP-40GD BH
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com.tw/support
http://www.advantech.com
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the FWA-1211 series Rev. A.
Part No. 2002121100
1 st Edition
December 2020
Specifications
Main Board Functions
• CPU: Intel Atom™ E3940/E3930
• BIOS: AMI™
• Memory: 1 x DDR3L 1333/1600/1867 MHz SODIMM, up
to 8 GB
• Ethernet:
- 5 x 10/100/1000 Mbps RJ45 via Intel i210-IT with 2
segment bypass
- 2 x10/100/1000 Mbps SFP via Intel i210-IS
• Storage: 1 x 2.5" internal SSD; 1 x mSATA slot (half size)
• Peripherals:
- USB:12x USB2.0 on front panel
- 2 x Power LED
- 1 x HDD LED
- 1 x Alarm LED
- 1 x Micro-HDMI
- 1 x Reset
- 1 x Console
- 2 x DB9 RS-232/422/485 seriel port (SKU option)
• Dimensions (W x L x H): 88 mm x 127 mm x 150 mm
• Weight: 3 Kg
• Environment: Operating
• Temperature: -40 °C ~ 70 °C
(-40 °F ~ 158 °F)
• Altitude: Below 5000 m
• Humidity: 5% ~ 95%
• IP Rating: IP40
Warning:
Please power off the machine and disconnect it from
all power source before you disassemble FWA-1211
machine.
This product is intended to be supplied by an UL Listed
power supply or dc source suitable for use at minimum
Tma 40 degree C whose output meets ES1, LPS, and
is rated 9-36Vdc, 4-1A. If need further assistance,
please contact Advantech for further information.
FWA-1211 Startup Manual 1
Non-operating
-40 °C ~ 85 °C
(-40 °F ~ 185 °F)
Advertisement
Related Manuals for Advantech FWA-1211
Summary of Contents for Advantech FWA-1211
- Page 1 Tma 40 degree C whose output meets ES1, LPS, and This manual is for the FWA-1211 series Rev. A. is rated 9-36Vdc, 4-1A. If need further assistance, please contact Advantech for further information.
-
Page 2: Specification
1. Unfasten the screws (red arrows), take out and keep for later, then loosen the screws circled in red and remove the heatsink. Installing the memory 1. Prepare the memory. Back view: 2. Insert into the slot as below and press the memory until locked. 2 FWA-1211 Startup Manual... - Page 3 5. Take two thermal pads from the assembly box. 1. Prepare the mSATA. 2. Insert the msata storage into the slot as below. 6. Replace the heatsink and fix the screws as below. 3. Take the screw from the assembly box. 7. Then fix the screws on the heatsink. 4. Fix as below. FWA-1211 Startup Manual 3...
- Page 4 4. Connect the SATA cable and the power cable as shown below. 2. Take 4 screws out of the accessory box as below and fix the SSD onto the the bracket. 5. Route the cable to the side of the mainboard as shown below. 6. Put on the heatsink and fix wth the screws as shown below. 4 FWA-1211 Startup Manual...
-
Page 5: Jumpers And Connectors
Clear CMOS jumper PSON1 AT/ATX mode select 3. Install the machine on the bracket accordingly. Jumper Name Pin Default Setting Function Jumper short Normal status JCMOS1 open Clear CMOS Jumper short AT mode PSON1 open ATX mode FWA-1211 Startup Manual 5... - Page 6 Battery Holder for Coin Battery Ground Pin Number Pin Name Function Ground VBAT1 3V battery power +V12 12V power Ground PWR_BTN1 WB_2V_2.00mm Power Button Signal Pin Header Pin Number Pin Name Function PANSWIN# Power button signal Ground 6 FWA-1211 Startup Manual...
- Page 7 Signal of COM1 for Reset 8051 & clock for RST/C2CK system console C2 interface Ground data for C2 interface Signal of COM1 for Ground system console Signal of COM1 for system console Signal of COM1 for system console FWA-1211 Startup Manual 7...
- Page 8 Jumpers and Connectors (Cont.) Figure 1: Location List of Jumper and Connector on Mainboard 8 FWA-1211 Startup Manual...
- Page 9 PGND Ground PWR_BTN1 DC_A Power A input ALM2 Signal of alerm2 WB_2V_2.00mm ALM1 Signal of alerm1 PGND Ground Power Button Connector DC_B Power B input Pin Number Pin Name Function PWRBTN_IN Signal of power button Ground FWA-1211 Startup Manual 9...
- Page 10 Jumpers and Connectors (Cont.) Figure 2: Location List of Jumper and Connector on PWR Board 10 FWA-1211 Startup Manual...
- Page 11 Clear CMOS Pin Header CONN_COM2_ Jumper Name Pin Default Setting Function RTS of RS-232 RTS# GPIO select 5V Jumper short DCD of RS-232/ level CONN_COM2_ J_GPIO1 TX- of RS-422/D of DCD/422TX-/485D- PSON1 GPIO select RS-485 Open 3.3V level FWA-1211 Startup Manual 11...
- Page 12 Signal of GPIO7 No connect +V_GPIO Power of GPIO Ground Ground Ground 8051_JTAG1 Ground PH_3x1V_2.00mm <Characteristic> 8051 _JTAG1 Pin Header Pin Number Pin Name Function Reset 8051 & clock for RST/C2CK C2 interface data for C2 interface Ground 12 FWA-1211 Startup Manual...
- Page 13 Jumpers and Connectors (Cont.) Figure 3: Location List of Jumper and Connector on EXT Board FWA-1211 Startup Manual 13...
-
Page 14: Safety Instructions
17. RESTRICTED ACCESS AREA: The equipment should only be installed in a Restricted Access Area. 18. DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the ac- curacy of any statements contained herein. - Page 15 équivalent recommandé par le fabricant, jetez les piles usagées conformément aux instructions du fabricant. 17. ZONE D’ACCES RESTREINTE: L’équipement ne doit être installé que dans une zone d’accès restreint. 18. AVERTISSEMENT: Cet ensemble d’instructions est donné conformément à la CEI 704-1. Advantech décline toute respon- sabilité quant à l’exactitude des déclarations contenues dans ce document.
