4. Specification

Working voltage
Input voltage
Output voltage
Dynamic current
Idle current
Working environment
temp
Output
Local-storage
Photo storage format
Video storage format
Control method
Mechanical Range
Controllable Range
Vibration angle
Hardware Parameter
12V
3S ~ 6S
5V (connect with PWM)
450~700mA @ 12V
450mA @ 12V
-20℃ ~ +60℃
IP (720p/1080P 25/30fps)
SD card (Up to 128G,class 10, FAT32)
JPG (1920*1080/1280*720)
MP4 (1080P/720P 25fps/30fps)
PWM / TTL / S.BUS / TCP
Gimbal Spec
Pitch/Tilt: -60°～120°,
Yaw/Pan: ±360°*N (IP output version)
Pitch/Tilt: -45°～90°, Yaw/Pan: ±360°*N
(IP output version)
Pitch/Roll: ±0.02°, Yaw：±0.02°
EH10 10X Optical Zoom Camera User Manual EH10 10X Optical Zoom Camera
Roll: ±35°,
