3.3 S.BUS Control

Control the gimbal camera functions by one combining signals.
Connect the external S.Bus to S.Bus port on the control box, and the
external S.bus signal GND connect to the GND interface of the control
box.
Wiring Diagram (Take Futaba remote control for example):
5V OUTPUT
GND
Remote Control Receiver
Wiring Diagram (Standard Version)
