3.1.2 PWM Control Operation Instruction
1) Pitch (PWM Pitch channel in to control Pitch. Joystick, rotary knob
or 3-gear switch on remote control are optional. 3-gear switch as
example.)
Position 1
Low Gear
Pitch Up
2) Yaw (PWM Yaw channel in to control Yaw. Joystick, rotary knob or
3-gear switch on remote control are optional. 3-gear switch as
example.)
Position 1
Low Gear
Yaw Left
3) Mode (PWM Mode channel in to adjust speed control/one key to
Home position etc functions. Rotary knob or 3-gear switch on remote
control are optional. 3-gear switch as example.)
EH10 10X Optical Zoom Camera User Manual EH10 10X Optical Zoom Camera
Position 2
Middle Gear
Pitch Stop
Position 2
Middle Gear
Yaw Stop
Position 3
High Gear
Pitch Down
Position 3
High Gear
Yaw Right
