Summary of Contents for Ruijie RGOS 11.X
- Page 1 Ruijie RGOS 11.X High-end Data Center Switches (N18000-X) Installation...
- Page 2 Contents ■ Hardware Installation...
-
Page 3: Hardware Installation
Hardware Installation Installing the Chassis Installing Power Preparations to a Specified Grounding Checking Modules or Cards Position Tip: Read the Hardware Installation Manual if you install the switch for the first time. Safety Notes Do not install the switch in a wet place and keep it away from liquid. ... - Page 4 Hardware Installation Installing the Chassis Installing Power Preparations to a Specified Grounding Checking Modules or Cards Position Confirming the Cabinet Specifications The cabinet depth (distance between the front and rear doors) must be large than 1200 mm. There must be a distance of more than 180 mm Figure 1 between the front mounting rails and front door of the cabinet, and the thickness of the front door...
- Page 5 Hardware Installation Installing the Chassis Installing Power Preparations to a Specified Grounding Checking Modules or Cards Position Unpacking: An N18000-X series switch is packed in carton, so it can be unpacked more quickly than an N18000 series switch. You will find a wrench and a screwdriver in the carton.
- Page 6 Hardware Installation Installing the Chassis Installing Power Preparations to a Specified Grounding Checking Modules or Cards Position Moving the Chassis: Operation by Four Persons Recommended Precautions: 1. Do not hold the panels, power module handles, or chassis handles when moving the chassis.
- Page 7 Hardware Installation Installing the Installing Power Preparations Chassis to a Grounding Checking Modules or Cards Specified Position Installing Shelf Brackets An N18000-X chassis is delivered with a pair of expandable shelf brackets. Reserve 2 U height above the cabinet bottom for shelf bracket installation. The two shelf brackets are marked RIGHT and LEFT to identify their installation positions.
- Page 8 Hardware Installation Installing the Installing Power Preparations Chassis to a Grounding Checking Modules or Cards Specified Position There Is a Ground Bar in the Installation Environment (Recommended) ① Remove the ground screw from the rear panel of the chassis. ② Put the OT terminal of the ground cable delivered with the switch on the ground screw of the chassis.
-
Page 9: Installing Power Modules
Hardware Installation Installing the Installing Power Preparations Chassis to a Grounding Checking Modules or Cards Specified Position Installing Power Modules All the chassis models have power module slots at two sides of the chassis. Precautions: Ensure that there are no objects, such as a PDU, near the rear mounting rails within depth of the chassis in the cabinet to hinder installation or removal of power... -
Page 10: Installing Line Cards
Hardware Installation Installing the Installing Power Preparations Grounding Checking Chassis to a Modules or Cards Specified Position Installing Line Cards Caution: N18000-X line cards do not use self-locking ejector levers. - Page 11 Hardware Installation Installing the Installing Power Preparations Chassis to a Grounding Checking Modules or Cards Specified Position Installing FE Switch Fabric Modules...
- Page 12 Hardware Installation Installing the Installing Power Preparations Chassis to a Grounding Checking Modules or Cards Specified Position Checking the Cabinet Ensure that the external power supply system matches the power distribution panel of the cabinet. Ensure that the front and rear doors of the cabinet can be closed with the switch in the cabinet. Ensure that the cabinet is securely fixed and will not move or fall down.
