Ruijie RG-S6000C-48GT4XS-E Switch
Hardware Installation and Reference Guide
Document Version: V2.0
Date: August 31, 2023
Copyright © 2023 Ruijie Networks

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RG-S6000C-48GT4XS-E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ruijie RG-S6000C-48GT4XS-E

Summary of Contents for Ruijie RG-S6000C-48GT4XS-E

  • Page 1 Ruijie RG-S6000C-48GT4XS-E Switch Hardware Installation and Reference Guide Document Version: V2.0 Date: August 31, 2023 Copyright © 2023 Ruijie Networks...
  • Page 2 Due to product version upgrades or other reasons, the content of this document will be updated from time to time. Ruijie Networks reserves the right to modify the content of the document without any notice or prompt. This manual is for reference only. Ruijie Networks endeavors to ensure content accuracy and will not shoulder any responsibility for losses and damages caused due to content omissions, inaccuracies or errors.

  • Page 3: Preface

    Preface Intended Audience This document is intended for:  Network engineers  Technical support and servicing engineers  Network administrators Technical Support  Ruijie Networks website: https://www.ruijienetworks.com/  Technical support website: https://ruijienetworks.com/support  Case portal: https://caseportal.ruijienetworks.com  Community: https://community.ruijienetworks.com ...
  • Page 4 Specification An alert that contains a description of product or version support. 2. Note The manual offers configuration information (including model, port type and command line interface) for indicative purpose only. In case of any discrepancy or inconsistency between the manual and the actual version, the actual version prevails.

  • Page 5: Table Of Contents

    Contents Preface ..............................I 1 Overview ............................1 1.1 About the RG-S6000C-48GT4XS-E ..................1 1.2 Component Modules ........................1 1.3 Chassis ............................2 1.3.1 Appearance ........................2 1.3.2 LEDs ..........................4 1.3.3 Ports ..........................6 1.3.4 Cooling ........................... 8 1.3.5 Technical Specifications ....................9 1.3.6 Nameplate ........................
  • Page 6 2.1 Safety Guidelines ........................27 2.1.1 General Precautions ....................27 2.1.2 Chassis-Lifting Guidelines ................... 27 2.1.3 Electricity Safety ......................28 2.1.4 Preventing ESD Damage ..................... 28 2.1.5 Laser Safety ......................... 29 2.1.6 Storage Guidelines ...................... 29 2.2 Site Requirements ........................29 2.2.1 Floor Loading .......................
  • Page 7 3.2 Installing the Rack........................39 3.2.1 Installation Guidelines ....................39 3.2.2 Procedure ........................39 3.3 Installing the Chassis ....................... 40 3.3.1 Installation Guidelines ....................40 3.3.2 Mounting the Brackets ....................40 3.3.3 Mounting the Chassis on the Rack ................41 3.3.4 Mounting the Chassis on the Wall ................
  • Page 8 3.9 Verifying Installation ......................... 54 3.10 Connecting the Power Cord ....................55 4 Commissioning ..........................55 4.1 Setting Up the Configuration Environment ................55 4.2 Powering on the Device ......................57 4.2.1 Checklist Before Power-on ..................57 4.2.2 Power-on ........................58 4.2.3 Checklist Before Power-on ..................
  • Page 9 6.2.5 Garbled Output on the Console ................... 64 6.2.6 Optical Port Linkdown ....................64 7 Appendix ............................64 7.1 Labeling Process ........................64 7.1.1 Hand Writing on Labels ....................64 7.1.2 Pasting Labels ......................65 7.1.3 Label Contents ......................66 7.2 Connectors and Media ......................

  • Page 10: Overview

    Ruijie Networks for data centers and high-end campuses. The RG-S6000C- 48GT4XS-E switch provides high-density Gigabit access, 10GE uplink ports, and diverse data center features. It can be used with Ruijie’s RG-N18000-X and RG-S6920-4C switches for a high-performance and high-reliability data center network.

  • Page 11: Chassis

    For example, input 1 uses mains electricity (AC power) and input 2 use Uninterrupted Power Supply (UPS) DC power. Chassis The RG-S6000C-48GT4XS-E hardware system consists of a chassis, a power supply system, and a cooling system.  Power supply system: provides two power module slots and supports 1+1 power redundancy.
  • Page 12 Hardware Installation and Reference Guide Overview Figure 1-2 Rear View of the RG-S6000C-48GT4XS-E 2. Structure Figure 1-3 Front Panel Structure Table 1-3 Front Panel Components Component Status LED PWR1 status LED PWR2 status LED Management port LED Fan status LED...

  • Page 13: Leds

    Hardware Installation and Reference Guide Overview 1000BASE-T port status USB port Mini-USB port Management port 10GE SFP+ port Figure 1-4 Rear Panel Structure Table 1-4 Rear Panel Components Component Grounding stud Expansion module slot Fan module slot PWR1 module slot PWR2 module slot 1.3.2 LEDs...
  • Page 14 Hardware Installation and Reference Guide Overview Silkscreen Description Label Solid red: The system (including all modules) is not functioning properly. Solid yellow: The temperature exceeds the limit or the power consumption is not enough. Off: The system is not receiving power or not operating even after receiving power.

  • Page 15: Ports

    Hardware Installation and Reference Guide Overview Silkscreen Description Label traffic at 1/10 Gbps. Off: No link is detected for the port. Solid yellow: The port has made a successful 10/100 Mbps link. Blinking yellow: The port is sending and receiving traffic at 10/100 Mbps.
  • Page 16 Hardware Installation and Reference Guide Overview Port Connector Type Description Accessory IEEE802.3ae Working mode: Full- duplex Optical attributes: Subject to the module or cable The management port is used to set up the onsite or remote configuration environment. Standards compliance: CAT5 or higher Management port RJ45...

  • Page 17: Cooling

    1.3.4 Cooling 1. Overview The RG-S6000C-48GT4XS-E adopts the front-to-rear airflow. Air flows in through the ports and out through the power module, as shown in Figure 1-5. Caution  Maintain a minimum clearance of 200 mm (7.87 in.) around the equipment for air circulation.

  • Page 18: Technical Specifications

    Hardware Installation and Reference Guide Overview 2. Airflow Figure 1-5 Front-to-Rear Airflow 1.3.5 Technical Specifications Table 1-7 Technical Specifications Class Item Specification 1.0 GHz dual-core Memory 1 GB, SDRAM Technical indicators NOR flash: MB (for BootROM) Flash memory NAND flash: 512 MB Without packing materials: 440 mm x 300 mm x Dimensions 44 mm (17.32 in.
  • Page 19 Hardware Installation and Reference Guide Overview Class Item Specification Two power module slots One fan module slot 48 x Gigabit ports, aligned to IEEE 1000BASE-T Downlink port specifications, backward compatible with 100BASE-T and 10BASE-T 4 x 10GE SFP+ ports, aligned to IEEE 10GBase-R Uplink port specifications, backward compatible with 1000BASE- Ports...
  • Page 20 Hardware Installation and Reference Guide Overview Class Item Specification condensing) Noise Sound pressure level at 27° C(80.6° F): < 78 dB AC power protection Surge protection Common mode: 2 kV Differential mode: 1 kV Power supply mode High-voltage DC (HVDC) Power connector Three-pin connector, subject to the power module Max: 60 W...
  • Page 21 Hardware Installation and Reference Guide Overview Class Item Specification Rated voltage: –48 V DC ○ ○ Max. current: 3.15 A RG-PA70I: 70 W Max. output power consumption RG-PD70I: 70 W RG-PA70I: Front-to-rear airflow (air exhaust on power module panel) Airflow direction RG-PD70I: Front-to-rear airflow (air exhaust on power module panel) Cooling mode...

  • Page 22: Nameplate

    18 kg (39.68 lbs.) in weight. Figure 1-6 Nameplate Location Power Modules The smart power modules for the RG-S6000C-48GT4XS-E support power consumption management and hot swapping. They can obtain the output power, output current, and operating temperature in real time. Caution ...

  • Page 23: Rg-Pa70I

    Hardware Installation and Reference Guide Overview 1.4.1 RG-PA70I 1. Appearance Figure 1-7 Appearance Figure 1-8 Structure...
  • Page 24 Hardware Installation and Reference Guide Overview Table 1-8 Components Component Description Latch Latch of the power cord Power Three-pin connector connector Handle Handle of the power module Latch Latch of the power module Power status LED 2. LED Table 1-9 Silkscreen Description Label...
  • Page 25 Hardware Installation and Reference Guide Overview 3. Technical Specifications Table 1-10 Technical Specifications Item Specification Without packing materials: 50.5 mm x 156 mm x 38 mm (1.99 Dimensions (W x D x H) in. x 6.14 in. x 1.50 in.) Weight Without packing materials: 0.395 kg (0.87 lbs.) Power connector...

  • Page 26: Rg-Pd70I

    Hardware Installation and Reference Guide Overview 1.4.2 RG-PD70I 1. Appearance Figure 1-9 Structure Table 1-11 Components Component Description Handle Handle of the power module Power status LED Power Three-pin connector connector Latch Latch of the power module 2. LED Table 1-12 Silkscreen Description Label...
  • Page 27 Hardware Installation and Reference Guide Overview Blinking green at 1 Hz: ○ The power module is in PS OFF state with only 12 V standby output. ○ The power module is in the cold standby status and not outputting power. Solid red: ○...

  • Page 28: Fan Module

    Hardware Installation and Reference Guide Overview Item Specifications Hot swapping Supported Cooling Front-to-rear airflow (air exhaust on power module panel) Overvoltage protection Supported Overcurrent protection Supported Over-temperature protection Supported Fan Module 1.5.1 M6000E-FAN-F 1. Appearance Figure 1-10 Appearance...
  • Page 29 Hardware Installation and Reference Guide Overview Figure 1-11 Structure Table 1-14 Components Component Description Captive screw Captive screw of the fan module Handle Handle of the fan module Airflow direction Front-to-rear airflow (air exhaust on fan module panel) notation Fan status LED 2.

  • Page 30: Cables

    Hardware Installation and Reference Guide Overview 3. Technical Specifications Table 1-16 Technical Specifications Item Specification Without packing materials: 150 mm x 100 mm x 40 mm (5.91 Dimensions (W x D x H) in. x 3.94 in. x 1.57 in.) Weight Without packing materials: 0.375 kg (0.83 lbs.) Number of fans...

  • Page 31: Ethernet Cable

    Hardware Installation and Reference Guide Overview Figure 1-12 Console Cable Structure Table 1-17 Console Cable Components Component Description B connector RJ45 connector with shielded crystal head A connector DB9 RS-232 female connector with blue rubber core Screw Screw Cable UL2464, 26 AGW sleeve 1.6.2 Ethernet Cable...

  • Page 32: Power Cord

    2. AC/HVDC Power Cord Select AC power cords based on the types of power sockets used in your equipment room. Ruijie provides the following types of AC power cords to suit different the power sockets:  Power distribution unit (PDU) cords: C13 straight female to C14 straight male AC power cords, delivered with a PDU with C14 straight female connectors, as shown in Figure 1-13.
  • Page 33 Hardware Installation and Reference Guide Overview Figure 1-13 IEC Standard Power Cord Structure Figure 1-14 GB Standard Power Cord Structure 3. DC Power Cord DC power cords include –48 V power cords and RTN power cords. Choose appropriate DC power cords for different scenarios: ...

  • Page 34: Grounding Wire

    Hardware Installation and Reference Guide Overview Table 1-19 DC Power Cord Components Component Description Cable sleeve UL1015, 16AWG, red Cable sleeve UL1015, 16 AWG, blue Cable sleeve UL1015, 16AWG, yellow/green Three 3S99601-000G9-W lug Three E1512 lug Three RNB2-6 lug 1.6.4 Grounding Wire Figure 1-16 Grounding Wire Structure...

  • Page 35: Pluggable Modules

    Caution  Always use Ruijie certified pluggable modules. Uncertified pluggable modules may lead to service instability. Ruijie will not claim responsibility for the service problems caused by uncertified pluggable modules or provide a solution.  The models of pluggable modules applicable to the chassis are subject to update without prior notification.

  • Page 36: Preparing For Installation

    Hardware Installation and Reference Guide Preparing for Installation Preparing for Installation Safety Guidelines Note  To avoid personal injury or equipment damage, review the safety guidelines in this chapter before you begin the installation.  The following safety precautions may not include all the potentially hazardous situations. 2.1.1 General Precautions ...

  • Page 37: Electricity Safety

    Hardware Installation and Reference Guide Preparing for Installation packing carton during transportation. Avoid placing the chassis side up or upside down.  Do not stack bare demo units. Separate demo units using foam blocks. Do not stack over three layers, each with a height of up to 1 meter (3.28 ft.). Lay the foam blocks side-by-side. 2.1.3 Electricity Safety ...

  • Page 38: Laser Safety

    Hardware Installation and Reference Guide Preparing for Installation 2.1.5 Laser Safety The optical transceivers are Class I laser products. Attention should be paid to the following items:  When an optical transceiver is working, ensure that the port is connected to an optical cable or covered by a dust cap to keep out dust and prevent burning your eyes.

  • Page 39: Temperature

    Hardware Installation and Reference Guide Preparing for Installation easily.  The front and rear of the chassis must remain unobstructed to ensure adequate airflow and prevent overheating inside the chassis. 2.2.4 Temperature To ensure normal operation and prolonged service life of the equipment, maintain an appropriate temperature in the equipment room.

  • Page 40: System Grounding

    Hardware Installation and Reference Guide Preparing for Installation Table 2-1 Dust and Particles Requirement Minimum Dust and Unit Maximum Quantity Particles Diameter 0.5 μm 3.5 x 10 Particles/m 5 μm Particles/m 3.0 x 10 Apart from dust, there are also requirements on the salt, acid, and sulfide in the air of the equipment room.

  • Page 41: Preventing Electromagnetic Interference

    Hardware Installation and Reference Guide Preparing for Installation Ensure that the rack and power distribution system are securely grounded. Otherwise, electric shocks may occur when the insulation resistance between the power module and the chassis becomes small. Caution The building should provide a protective ground connection to ensure that the equipment is connected to a protective earth.

  • Page 42: Surge Protection

    Hardware Installation and Reference Guide Preparing for Installation  Interference prevention measures should be taken for the power supply system.  Keep the equipment far away from the grounding facility and surge protector facility of the power device.  Keep the equipment far away from high-frequency current devices such as the high-power radio transmitting station and radar launcher.

  • Page 43: Tools

    Hardware Installation and Reference Guide Preparing for Installation (3) The square hole rack post is at least 180 mm (7.09 in.) from the front door, and the front door is at most 25 mm (0.98 in.) thick. This ensures an available clearance of at least 155 mm (6.10 in.).

  • Page 44: Unpacking The Container

    Hardware Installation and Reference Guide Preparing for Installation Note The preceding items are delivered against the purchase contact. Check your goods carefully against Package Contents or purchase contract. If you have any questions, contact your distributor. 2.5.2 Unpacking the Container Cut off the packing straps on the shipping box with scissors, place the box on a flat surface, and check whether the seal on top of box is intact.
  • Page 45 Hardware Installation and Reference Guide Preparing for Installation Figure 2-5 Figure 2-6 Place the switch with the panel foam facing upwards. Remove the panel foam and set it aside. Move the switch with both hands onto the shipping box of another product, and remove the foam on the other side.

  • Page 46: Installing The Switch

    Hardware Installation and Reference Guide Installing the Switch Figure 2-7 (8) Press the power module inward to ensure that the power module is fully seated into the system. Installing the Switch Make sure that guidelines and requirements in chapter 2 have been met before you begin the installation.

  • Page 47: Installation Procedure

    Hardware Installation and Reference Guide Installing the Switch Installation Procedure Figure 3-1 Installation Procedure Start Prepare Install the chassis. Connect the grounding wire. Install the power module. Connect the power cord. Verify installation. Set the power Troubleshoot switch to ON. Set the power Normal? switch to OFF.

  • Page 48: Installing The Rack

    Hardware Installation and Reference Guide Installing the Switch Installing and Removing the Expansion Module Installing and Removing the Power Module Installing the Pluggable Module Verifying Installation Connecting the Power Cord Installing the Rack 3.2.1 Installation Guidelines Make sure the following guidelines are met: ...

  • Page 49: Procedure

    Hardware Installation and Reference Guide Installing the Switch 3.2.2 Procedure (1) Make sure that there is enough space before installing the rack. Reserve enough clearance before the front and rear doors for equipment maintenance. (2) Mount and fasten the rack in the planned location. (3) Install the appropriate chute and cables.

  • Page 50: Mounting The Chassis On The Rack

    Hardware Installation and Reference Guide Installing the Switch Figure 3-2 Installing the Brackets 3.3.3 Mounting the Chassis on the Rack The chassis can be installed on a standard 19-inch EIA rack. Mount the chassis on the rack with its front panel facing forward. You are advised to use a tray or guide rails to assist in installing the chassis on the rack.

  • Page 51: Mounting The Chassis On The Wall

    Hardware Installation and Reference Guide Installing the Switch Figure 3-3 Mounting the Chassis on the Rack Caution  Install the L-bracket by driving screws into the four among six screw holes on each side.  Distinguish left and right rack-mount guide rails according to the notations. ...

  • Page 52: Mounting The Chassis On The Workbench

    Hardware Installation and Reference Guide Installing the Switch Figure 3-4 Mounting the Chassis on the Wall 3.3.5 Mounting the Chassis on the Workbench If a standard 19-inch EIA rack is not available, mount the switch on a clean workbench. Lay the chassis flat on the workbench and ensure adequate airflow around the chassis. Figure 3-5 Mounting the Chassis on the Workbench Installing the Protective Grounding Wire...

  • Page 53: Procedure

    Hardware Installation and Reference Guide Installing the Switch  Never use bare wires.  The combined grounding should have a grounding resistance of less than 1-ohm. 3.4.2 Procedure (1) Remove the grounding screw on the rear panel. (2) Crimp one end of the grounding wire to the grounding terminal of the chassis and the other end to the grounding terminal of the rack or the grounding bar of the equipment room.

  • Page 54: Removing The Fan Module

    Hardware Installation and Reference Guide Installing the Switch Figure 3-6 Installing the Fan Module Warning  Slide the fan module all the way into the chassis gently. Align the fan module in the right orientation to the open fan slot. ...

  • Page 55: Installing And Removing The Expansion Module

    Hardware Installation and Reference Guide Installing the Switch Figure 3-7 Removing the Fan Module Warning  Pull the fan module out of the slot gently.  If the fan module slot is to remain empty, install a filler panel to allow for adequate airflow and to keep dust out of the chassis.

  • Page 56: Removing The Expansion Module

    Hardware Installation and Reference Guide Installing the Switch Figure 3-8 Installing the Expansion Module Warning  Do not hold the PCB by its edges or touch components on the PCB.  Slide the expansion module all the way into the chassis gently. Align the expansion module in the right orientation to the open slot.

  • Page 57: Installing And Removing The Power Module

    Hardware Installation and Reference Guide Installing the Switch Figure 3-9 Removing the Expansion Module Warning  Do not hold the PCB by its edges or touch components on the PCB.  Pull the expansion module out of the slot gently. ...
  • Page 58 Hardware Installation and Reference Guide Installing the Switch Figure 3-10 Installing the RG-PA70I Warning  Slide the power module all the way into the chassis gently. Align the power module in the right orientation to the open power slot.  If you are not able to push the power module all the way into the slot, carefully slide the module out of the slot, align the module with guide rails, and reinstall the module.
  • Page 59 Hardware Installation and Reference Guide Installing the Switch Figure 3-11 Retainer Strip, Retainer Clamp, and Latches (2) Thread the retainer strip through the hole at the bottom of the clamp and lock it into place, as shown in Figure 3-12. If you want to remove the strip, press the retainer strip latch and pull the strip out.

  • Page 60: Installing The Rg-Phd550I-F

    Hardware Installation and Reference Guide Installing the Switch Figure 3-13 Retainer Clamp 3.7.2 Installing the RG-PHD550I-F (1) Remove the power module from its packing materials. Make sure the input indicators meet the requirements. (2) Remove the filler panel from the slot by unscrewing the captive screw. Keep the panel with the nameplate facing upwards.

  • Page 61: Installing The Rg-Pd70I

    Hardware Installation and Reference Guide Installing the Switch Figure 3-14 Installing the RG-PHD550I-F (3) Connect the other end of power cord to the DC terminal board. Connect the blue, red, and yellow-green wires to –48 V DC, –48 V GND, and PGND terminals respectively. Figure 3-15 Installing the Power Cord Retainer Warning...
  • Page 62 Hardware Installation and Reference Guide Installing the Switch (2) Remove the filler panel from the slot by unscrewing the captive screw. Keep the panel with the nameplate facing upwards. Grasp the handle with one hand and place your other hand underneath the power module to support it.

  • Page 63: Removing The Power Module

    Hardware Installation and Reference Guide Installing the Switch 3.7.4 Removing the Power Module (1) Disconnect the power cord from the power module. (2) Press the latch on the power module and pull it halfway out of the slot. Grasp the power module by the handle and gently pull it straight out of the slot, keeping your other hand under the power module to guide it.

  • Page 64: Installing The Pluggable Module

    Make sure that you have mounted the chassis on the rack before installing the pluggable module.  For procedure, see Ruijie Optical Module Hardware Installation and Reference Guide for details. The documentation is subject to update without prior notification. Please access Ruijie Networks at https://www.ruijienetworks.com/...

  • Page 65: Connecting The Power Cord

    Hardware Installation and Reference Guide Commissioning  Never assume that power is disconnected from a circuit. Instead, always check.  The power cord is plugged into the power module and retained there.  The power cord is long enough to avoid over-extension. ...
  • Page 66 Hardware Installation and Reference Guide Commissioning Figure 4-1 Configuration Environment Device Console port Serial port Console cable The first login to the device must be performed through the console port. (1) Connect the serial port of a PC to the console port of the device with a standard RS-232 cable. (2) Set up a local configuration environment through the console port on the front panel.

  • Page 67: Powering On The Device

    Hardware Installation and Reference Guide Commissioning Click Open to set up the connection. (4) After setting up the configuration environment, power on the device. If the device is already configured with a password, a notification will appear. Click Accept, and enter your username and password for connection.

  • Page 68: Checklist Before Power-On

    Hardware Installation and Reference Guide Commissioning  The input voltage follows the requirement.  Check whether the cable is properly connected, whether the terminal such as a PC is started, and whether terminal parameters are configured. 4.2.2 Power-on Turn off the circuit breaker at the power supply end and set the power switch of the chassis to 4.2.3 Checklist Before Power-on ...

  • Page 69: Monitoring And Maintenance

    Hardware Installation and Reference Guide Monitoring and Maintenance Monitoring and Maintenance Monitoring 5.1.1 Monitoring the LEDs Each module installed in the chassis features a LED, which can be used to monitor the status 1 Overview of each module while the switch is running. See for details.

  • Page 70: Maintenance

    Hardware Installation and Reference Guide Monitoring and Maintenance Maintenance 5.2.1 Replacing the Power Module The power failure will be prompted through monitoring signals. In the case of a power failure, contact your distributor or technical support team. Installing and Removing the Power Module for procedure.

  • Page 71: Replacing The Fuse

    Hardware Installation and Reference Guide Monitoring and Maintenance 5.2.4 Replacing the Fuse To replace the fuse, please contact your distributor or technical support team. Table 5-2 Fuse Specifications Chassis Fuse Bits Specifications RG-S6000C-48GT4XS-E 5 A/125 V...

  • Page 72: Troubleshooting

    Hardware Installation and Reference Guide Troubleshooting Troubleshooting Flowchart The equipment is not working properly. Check whether the rack is installed properly. Check whether the chassis is mounted on the rack properly. Check whether the power cord is connected properly. Check whether the power module is installed properly.

  • Page 73: Common Issues

    Hardware Installation and Reference Guide Troubleshooting Common Issues 6.2.1 Forgetting Login Password Symptom The login password is forgotten. Handling Method Contact technical support team. 6.2.2 AC Power Module Failure Symptom All LEDs on the front panel are off. The fan status LED is off, and the fan does not rotate. Handling Method Unplug the power cord from the power module.

  • Page 74: Garbled Output On The Console

    Hardware Installation and Reference Guide Appendix 6.2.5 Garbled Output on the Console Symptom The console output is garbled. Handling Method The fault is related to the serial port configuration. Check whether baud rate configuration is consistent with that in Configuration Guide. 6.2.6 Optical Port Linkdown Symptom...

  • Page 75: Pasting Labels

    Hardware Installation and Reference Guide Appendix 7.1.2 Pasting Labels Fill in the label content on the full-page label paper before attaching the label, and then paste it on the power cord or signboard wire buckle. (1) Label pasting position Paste the label 2 cm (0.79 in.) away from the plug. In some specific situations, avoid cable bending or the position that affects power cord installation.

  • Page 76: Label Contents

    Hardware Installation and Reference Guide Appendix Figure 7-2 Signal Cable Labeling Procedure 7.1.3 Label Contents The contents of the two sides of the label identify the location of the ports connected to the two ends of the power cord. Fill in the label according to the specific environment. (1) Fill the content of the local end of the cord location in area ①.

  • Page 77: Connectors And Media

    Hardware Installation and Reference Guide Appendix Connectors and Media 7.2.1 100BASE-TX/10BASE-T Port Table 7-1 100BASE-TX/10BASE-T Pin Assignment MDI Mode MDI-X Mode Output Transmit Data+ Input Receive Data+ Output Transmit Data– Input Receive Data-– Input Receive Data+ Output Transmit Data+ Input Receive Data– Output Transmit Data–...
  • Page 78 Hardware Installation and Reference Guide Appendix Figure 7-5 Cable Connection Modes and Signals Table 7-2 1000BASE-T Pin Assignment MDI Mode MDI-X Mode Media Dependent Interface A+ Media Dependent Interface B+ Media Dependent Interface A– Media Dependent Interface B– Media Dependent Interface B+ Media Dependent Interface A+ Media Dependent Interface C+ Media Dependent Interface D+...

  • Page 79: Surge Protection

    Hardware Installation and Reference Guide Appendix Figure 7-6 1000BASE-T Twisted Pair Connections Surge Protection 7.3.1 Installing an AC Power Arrester When an AC power cord from outdoors is directly plugged into the power port of the switch, the AC power connector must be connected to an external surge protector power strip to protect the switch against lightning strikes.
  • Page 80 Hardware Installation and Reference Guide Appendix Figure 7-7 Power Arrester Note The power arrester does not come with the equipment. Please purchase it based on actual requirements. Important points:  Make sure that the PE terminal of the power arrester is well grounded. ...

  • Page 81: Installing An Ethernet Port Arrester

    Hardware Installation and Reference Guide Appendix 7.3.2 Installing an Ethernet Port Arrester Please connect an Ethernet port arrester to the switch to prevent the damage by lightning before connecting an outdoor network cable to the switch. Tools: Phillips screwdrivers or flat-head screwdriver, multimeter, and diagonal pliers Procedure: (1) Tear one side of the protective paper for the double-sided adhesive tape and paste the tape to the enclosure of the Ethernet port arrester.

  • Page 82: Site Selection

    Hardware Installation and Reference Guide Appendix Caution is needed to avoid the following cases:  Reversed installation direction of the arrester. Connect the external network cable to the IN end and connect the Ethernet port of the switch to the OUT end. ...

  • Page 83: Recommended Cabling

    Hardware Installation and Reference Guide Appendix wall or window, take proper sealing measures. Ensure that the wall is flat, wear-resistant, and dust-free, which should be up to the standard for flame retarding, soundproofing, heat absorption, dust reduction, and electromagnetic shielding. ...
  • Page 84 Hardware Installation and Reference Guide Appendix Figure 7-9 Bundling Up Cables (1)  Cables of different types (such as power cords, signal cables, and grounding wires) should be separated in cabling and bundling. Mixed bundling is not allowed. When they are close to each other, you are advised to adopt crossover cabling.
  • Page 85 Hardware Installation and Reference Guide Appendix will be bent, as shown in Figure 7-11. Figure 7-11 Bundling Up Cables (3)  Cables not to be assembled or remaining parts of cables should be folded and placed in a proper position of the rack or cable trough. The proper position refers to a position that does not affect switch performance or damage the switch or cable.
  • Page 86 Hardware Installation and Reference Guide Appendix  Do not use self-tapping screws to fasten terminals.  Power cords of the same type and in the same cabling orientation should be bundled up into one cable bundle. The power cords in the bundle should be clean and straight. ...
