Hardware Installation
Preparations
There Is a Ground Bar in the Installation Environment
(Recommended)
① Remove the ground screw from the rear panel of the
chassis.
② Put the OT terminal of the ground cable delivered
with the switch on the ground screw of the chassis.
③ Install the ground screw with the OT terminal to the
ground hole, fasten it with a screwdriver, and connect
the other end of the ground cable to the ground bar
of the equipment room. (Adjust the length of the
ground cable based on the distance with the ground
bar.)
There Is No Ground Bar in the Installation Environment
If the switch adopts AC power supply, the PE cable of the
AC power supply needs to be grounded. Check whether
the PE cable of the AC power supply is properly grounded
in the power distribution room or on the AC transformer
side.
Installing the
Chassis to a
Specified Position
Installing Power
Grounding
Modules or Cards
Checking
