DSP CORE CURRENT
TP14
VDDEXT_SHUNT
VDDEXT
R149
0.1
0603
C189
0.1UF
0603
A
U6
3
7
IN+
V+
2
4
IN-
V-
8
6
RG+
OUT
1
5
RG-
REF
AD623ARMZ
USOIC8
R150
25.5K
0603
DSP IO CURRENT
A5V
2
R147
10.0K
0603
3
C188
R148
0.01UF
10.0K
0402
0603
AGND
AGND
R151
90.9K
0603
U34
6
AD820ARZ
SOIC8
A5V
C191
0.01UF
0402
AGND
