CONFIGURATION
MTP61-<Contry range>
Country range:
EU:
470-832 MHz, Max power 50mW
EUX:
470-832 MHz, Max power 100mW
UK1:
470-663 MHz, Max power 100mW + 960-1075 MHz, Max power 50mW
UK2:
510-698 MHz, Max power 100mW + 960-1075 MHz, Max power 50mW
US*:
470-608 MHz,Max power 100mW+614-663 MHz,Max power 20mW+940-960 MHz,Max power 100mW
CA:
470-608 MHz,Max power 100mW+614-663 MHz,Max power 20mW+940-960 MHz,Max powe 100mW
KR:
510-698 MHz, Max power 100mW + 925-937,5 MHz, Max power 10mW
JPx: (
JP1 660-714 MHz, Max 10mW), JP2 (806-810 MHz, Max 10mW), JP3 (1240-1260 MHz, Max 50mW)
MX:
470-608 MHz, Max power 100mW+614-832 MHz,Max power 100mW
*Simultaneous recording and wireless transmission is not available on transmitters sold in the USA
ANTENNA RANGE & CONFIGURATION
Ant Label
507
590
552
646
710
796
808
950
1k1
1K2
MTP61 is supplied with
• 2 Lithium battery Model CS-BCE10
• 1 wire belt clip (BCLW61)
• antenna kit: according to the configuration of MTP61 the following kit antennas are supplied:
MTP61-US and MTP61-CA
AWSS-507 (470-547 Mhz)
AWSS-590 (548-663 Mhz)
AWSS-950 (940-960 Mhz)
MTP61-UK1
AWSS-507 (470-547 Mhz)
AWSS-590 (548-663 Mhz)
AWSS-1K1 (960-1160 Mhz)
MTP61-KR
AWSS-552 (510-595 Mhz)
AWSS-646 (595-698 Mhz)
AWSS-950 (940-960 Mhz)
14
MTP61
Code
AWSS-507
AWSS-590
AWSS-552
AWSS-646
AWSS-710
AWSS-796
AWSS-808
AWSS-950
AWSS-1K1
AWSS-1K2
multi-band miniature transmitter
Band MHz
470-547
547-663
510-595
595-698
663-760
760-832
806-810
925-960
960-1160
1240-1260
MTP61-UK2
AWSS-552 (510-595 Mhz)
AWSS-646 (595-698 Mhz)
AWSS-1K1 (960-1160 Mhz)
MTP61-EU / MTP61-EUX / MTP61-MX
AWSS-507 (470-547 Mhz)
AWSS-590 (548-663 Mhz)
AWSS-710 (663-760 Mhz)
AWSS-796 (760-832 Mhz)
MTP61-JP1/JP2/JP3
AWSS-710 (660-760 Mhz) or
AWSS-808 (806-810 Mhz) or
AWSS-1250 (1240-1260 Mhz)
