PROCISE™ Surround Sound Amplifier
PROCISE Amplifier
Connections
Connect a PROAMP-7X400 to a PSPHD Surround Sound Processor
Power Connections
14 • PROCISE™ Surround Sound Amplifier: PROAMP(I)-7X400
Refer to the following diagram to properly connect the PROAMP-7X400 to a
PSPHD Surround Sound Processor.
NOTE: For optimum performance when connecting a source to a PROCISE
amplifier, Crestron recommends the optional CBL-PRO-XLR-2 Balanced Audio
Interface Cable Kit (two-foot cable length) or CBL-PRO-XLR-6 Balanced Audio
Interface Cable Kit (six-foot cable length).
When making connections to the PROAMP-7X400, two independent AC feeds are
required.
Crestron PROAMP(I)-7X400
Operations Guide – DOC. 6976A
