Operations Guide – DOC. 6976A
PROCISE™ Surround Sound Amplifier

Troubleshooting

The following table provides corrective action for possible trouble situations. If
further assistance is required, please contact a Crestron customer service
representative.
PROAMP-7X400 Troubleshooting
TROUBLE POSSIBLE CAUSE(S)
Device does not Device is not
function. communicating with the
network.
Device is not paired with
a PSPHD.
Device does not Device is in the Override
respond to mode.
program control.
TEMP LED Excessive temperature
illuminates. inside amplifier.
FAULT LED DC offset voltage on
illuminates. speaker terminal.
Driving source level is
too high.
Operating temperature
is too high.
Both power plugs are
plugged into outlet on
the same circuit.
Device is not receiving
sufficient power.

Check Network Wiring

In order to ensure optimum performance over the full range of your installation
topology, Crestron Certified Wire and only Crestron Certified Wire may be used.
Failure to do so may incur additional charges if support is required to identify
performance deficiencies because of using improper wire.
When daisy-chaining Cresnet units, strip the ends of the wires carefully to avoid
nicking the conductors. Twist together the ends of the wires that share a pin on the
network connector and tin the twisted connection. Apply solder only to the ends of
the twisted wires. Avoid tinning too far up the wires or the end becomes brittle.
Insert the tinned connection into the Cresnet connector and tighten the retaining
screw. Repeat the procedure for the other three conductors.
Use of a Cresnet Hub/Repeater (CNXHUB) is advised whenever the number of
Cresnet devices on a network exceeds 20 or when the combined total length of
Cresnet cable exceeds 3000 feet (914 meters).
PROCISE™ Surround Sound Amplifier: PROAMP(I)-7X400 • 23
CORRECTIVE ACTION
Use Crestron Toolbox to poll
the network. Verify network
connection to the device.
Pair the amplifier with a
PSPHD.
Press OVERRIDE/SETUP to
exit the Override mode.
Provide better ventilation to
amplifier.
Remove DC source from
input signal. Press RESET to
turn off FAULT LED.
Lower output level of audio
source. Press RESET to turn
off FAULT LED.
Provide better ventilation to
amplifier.
Each power cord must be
plugged into a different
circuit.
Verify that each power cord is
plugged into a separate
circuit.
