Crestron PROCISE PROAMPI-7X400 Operation Manual page 13

Crestron PROAMP(I)-7X400
Operations Guide – DOC. 6976A
PROAMP-7X400 Overall Dimensions
6
4
1 2 3
5 7
10 11
PROCISE™ Surround Sound Amplifier
19.00 in
(483 mm)
17.28 in
(439 mm)
8 9
12 13 14
PROCISE™ Surround Sound Amplifier: PROAMP(I)-7X400 • 7
18.36 in
(467 mm)
21.14 in
18.12 in
(537 mm)
(461 mm)
17.86 in
(454 mm)
8.70 in
(221 mm)
9.24 in
(235 mm)
15
16
17
