DO Configure the Device
Configure the Crestron HD-DA-2 using DIP switches 1-7. The default setting of the DIP switches is
®
OFF.
ON
OFF
1 2 3 4 5 6 7 8
NOTE: DIP switch 8 is not used.
Refer to the following table for DIP switch functions and associated settings.
DIP Switch Functions 1 2
Audio Input Source
HDMI IN OFF
Selection
SPDIF Source ON
SPDIF Source,
AUDIO IN, SPDIF, RCA OFF
Audio Embedding
1
AUDIO IN, OPTICAL ON
Audio EDID Copy HDMI OUT 1
Control Audio EDID
2
Copy HDMI OUT 2
Audio EDID
LBR (DTS, AC3) or 2CH PCM
2CH PCM Only
Audio/Video EDID
Copy HDMI 1 EDID
Control (Primary
(Audio/Video)
3
EDID Control)
Copy HDMI 2 EDID
(Audio/Video)
3
Copy HDMI 1 EDID
(Video Only) 4
Copy HDMI 2 EDID
(Video Only) 4
Best Common Resolutions
(Video Only) 4
1. DIP switch 1 must be ON
2. May be overridden by DIP switches 5, 6, and 7
3. Overrides audio EDID set by DIP switches 3 and 4
4. DIP switches 3 and 4 control audio EDID
NOTE: Depending on the audio/video application, a DIP switch setting may be ignored.
NOTE: If DIP switch settings are changed after power is applied to the device, cycle power to the
device in order for the new DIP switch settings to be applied.
The following sections provide sample configurations and associated DIP switch settings for video
distribution, audio embedding, and audio extraction applications.
Video Distribution: The HD-DA-2 can be used to distribute one HDMI
devices using their best common video EDID information. In the example below, one HDMI video
source, a Blu-ray™ player, connects to the HDMI IN port of the HD-DA-2. Two displays connect to
the HDMI OUT 1 and HDMI OUT 2 ports on the HD-DA-2. The DIP switch settings shown below
configure the HD-DA-2 to both distribute video from the Blu-ray player to the two displays using
their best common video resolutions and to send 2CH PCM to both displays.
DIP Switch Settings
3 4 5 6 7
Blu-ray
player
TM Display
OFF OFF
Audio Embedding: The HD-DA-2 can be used to embed digital audio from DVI or HDMI sources
that do not transmit audio with the video (for example, video from a computer via a DVI-to-HDMI
ON OFF
conversion cable). Digital audio must then be sent to the HD-DA-2 separately from the video. In the
example below, the video output from a computer connects to the HDMI IN port of the HD-DA-2.
OFF ON
The digital audio output from the computer connects to the AUDIO IN OPTICAL port of the
ON ON
HD-DA-2. A display connects to the HDMI OUT 2 port on the HD-DA-2. The DIP switch settings
shown below configure the HD-DA-2 to receive video at the HDMI IN port, to embed audio from the
OPTICAL port, and to send audio and video to the HDMI OUT 2 port.
OFF OFF OFF
ON OFF OFF
OFF ON OFF
ON ON OFF
OFF OFF ON
DO Check the Box
QUANTITY PRODUCT
1 Power Pack, 24 Vdc 0.75 A, 100-240 Vac
® video source to two
1 2 3 4 5 6 7 8
DIP switch 2, represented by an X,
is ignored.
Display
1 2 3 4 5 6 7 8
DIP switches 3 and 4, each represented by
an X, are ignored.
Display
Audio Extraction: The HD-DA-2 can be used to extract audio from an HDMI source and feed the
audio to an AV receiver or amplifier or to both devices. In the example below, the HDMI source, a
Blu-ray player, connects to the HDMI IN port on the HD-DA-2. An AV receiver connects to the
AUDIO OUT SPDIF port, and an amplifier connects to the AUDIO OUT R and L ports. The DIP
switch settings shown below configure the HD-DA-2 to route audio from the Blu-ray player to the
AV receiver and amplifier.
AV
receiver
Ampli er
1 2
DIP switch 2, represented by an X,
is ignored.
TM
Blu-ray
player
Display
DO Set the HDCP Keys
Using the rotary switch and a small screwdriver, set the required number of HDCP keys. The rotary
switch allows up to 16 keys to be set: A-F correspond to 10-15, and 0 corresponds to 16.
NOTE: If a rotary switch setting is changed after power is applied to the device, cycle power to
the device in order for the new rotary switch setting to be applied.
PART NUMBER
2045865
3 4 5 6 7 8
