GE M
S
EDICAL
YSTEMS
D
5123449-100, R
IRECTION
_____________________________________________________________________________________________
5.2.2. Positioner Cabinet
30
230
340
All dimensions in mm
Cables can be routed into the cabinet from either side, back or directly into the button of the cabinet. Both side
openings and the back opening are the same size. A different panel – the two shown above as well as a third that is
solid, covers each opening. This allows the installer to choose which panel they prefer to use on opening where the
cables are routed.
Page 36 / 111
12
EVISION
1960mm
600mm
55
P
RECISION
340mm
70
20
June 2009
RX
S
P
-I
I
YSTEM
RE
NSTALLATION
30
50
