227mm
1978 mm
from
the
floor to the
holes
brackets
support
Required hardware for wall mounting (not provided)
Anchor diameter: 12mm
Anchor length: 50mm
Bolt diameter: 6mm
Wall loading requirement: 50kg per bolt
12
EVISION
Cabinet Anchoring Dimensions
Power cabinet fixed to the wall by anchors and bolts
fixation to the wall
June 2009
P
RX
RECISION
φ13mm
487mm
S
P
-I
I
YSTEM
RE
NSTALLATION
400 mm
Brackets
Table cabinet
Front view
