SCM188 NXP i.MX 8M Plus ARM-based SMARC Module

2.6 SMARC Module Top/Bottom Side Pinout Table

P-Pin Primary (Top) Side
P1 SMB_ALERT#
P2 GND
P3 CSI1_CK+
P4 CSI1_CK-
P5 NC
P6 NC
P7 CSI1_DP0
P8 CSI1_DN0
P9 GND
P10 CSI1_DP1
P11 CSI1_DN1
P12 GND
P13 CSI1_DP2
P14 CSI1_DN2
P15 GND
P16 CSI1_DP3
P17 CSI1_DN3
P18 GND
P19 GBE0_MDI3-
P20 GBE0_MDI3+
P21 GBE0_LINK100#
P22 GBE0_LINK1000#
P23 GBE0_MDI2-
P24 GBE0_MDI2+
P25 GBE0_LINK_ACT#
P26 GBE0_MDI1-
P27 GBE0_MDI1+
P28 NC
P29 GBE0_MDI0-
P30 GBE0_MDI0+
P31 NC
P32 GND
P33 SDIO_WP
P34 SDIO_CMD
P35 SDIO_CD#
P36 SDIO_CK
P37 SDIO_PWR_EN
P38 GND
P39 SDIO_D0
P40 SDIO_D1
10
S-Pin Secondary (Bottom) Side
S1 I2C2_SCL
S2 I2C2_SDA
S3 GND
S4 NC
S5 I2C3_SCL
S6 NC
S7 I2C3_SDA
S8 CSI0_CK+
S9 CSI0_CK-
S10 GND
S11 CSI0_DP0
S12 CSI0_DN0
S13 GND
S14 CSI0_DP1
S15 CSI0_DN1
S16 GND
S17 GBE1_MDI0+
S18 GBE1_MDI0-
S19 GBE0_LINK100#
S20 GBE1_MDI1+
S21 GBE1_MDI1-
S22 GBE0_LINK1000#
S23 GBE1_MDI2+
S24 GBE1_MDI2-
S25 GND
S26 GBE1_MDI3+
S27 GBE1_MDI3-
S28 NC
S29 NC
S30 NC
S31 GBE1_LINK_ACT#
S32 NC
S33 NC
S34 GND
S35 USB_DP_DN1
S36 USB_DM_DN1
S37 NC
S38 AUDIO_MCK
S39 AUDIO _TXFS
S40 AUDIO _TXD
Board and Pin Assignments
