ROLL-DOWN SECURITY DOOR - RETRACTED

Roll Down Security Door: Shown Retracted (Raised)
• Roll down security door has two handles for grasping, lowering and raising.
• After door is lowered, key may be turned clockwise to lock latch into strike bracket.
• Turn counter-clockwise to unlock.
• Keep keys in safe and secure place.
Handles (For Lowering &
Raising Security Door)
9
Lock Plate
Lock (Typ.)
Illustration Shown Reflects
Model HECO37R. Your Model
May Vary in Length.
