ROLL-DOWN SECURITY DOOR - EXTENDED

Roll-Down Security Door: Shown Extended
Roll-down security door has two handles ("A") for grasping, lowering and raising.
After door is lowered, use key to turn lock ("B") clockwise to insert the "plunger rod" into lock plate ("C");
Note: Lock plate is part of roll-down security door assembly.
Turn counter-clockwise to unlock.
Keep keys in safe and secure place.
See next page for view of case with roll-down security door in retracted (raised) position.
A
B
Enlarged View of Model HECO37R With Roll-Down
Security Door. Partially Disassembled and
Transparent For Illustrative Purposes Only.
C
B
Illustration Shown Reflects Model HECO37R
With Roll-Down Security Door.
Your Model May Vary in Length.
