Summary of Contents for Advantech PPC-306 EHL
Page 1
User Manual PPC-306 EHL ® 6.5" Fanless Panel PC with Intel ® Celeron N6210 Processor...
Page 2
No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. The information provided in this manual is intended to be accurate and reliable.
Page 3
(ESD) or electromagnetic interference (EMI) leakage, we strongly recommend using CE-compliant industrial enclosure products. Technical Support and Assistance Visit the Advantech website at http://support.advantech.com to obtain the latest product information. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. Please have the following information ready before calling: –...
Page 4
Remplacer uniquement avec une pile du même type ou d’un type équiva- lent recommandé par le constructeur. In accordance with the IEC 704-1:1982 specifications, the sound pressure level at the operator’s position should not exceed 70 dB (A). PPC-306 EHL User Manual...
Page 5
AVERTISSEMENT: Ces instructions sont fournies conformément aux normes IEC 704-1. Advantech decline toute responsabilité quant à la précision de toute déclaration contenue dans le présent document. Do not expose the equipment to direct sunlight, or install the equipment in an environment with direct sunlight, as this may cause damage.
Page 6
Remplacer les produits identiques ou équiva- lents recommandés par le fabricant. Traitement des piles usagées selon les instructions du fabricant.” Note! Notes provide additional information. Revision Date Version Description/Change September 2023 Initial PPC-306 EHL User Manual...
Introduction Advantech's PPC-306 EHL is an all-in-one light panel PC with a wide format 6.5" TFT ® ® LCD screen. It is powered by an Intel Celeron N6210 processor, PPC-306 EHL to provide high performance, optimal memory, graphics, and peripheral I/O support in a compact, fanless, embedded system.
Rear Panel The PPC-306 EHL rear panel features four VESA mount (75 x 75 mm /2.95 x 2.95 in) holes located on its bottom side, as demonstrated below: VESA mount screws: 4 x M4 screws, screw depth: 8 mm (max.) Figure 1.2 Rear Panel...
197.6 x 150.6 x 41 mm (7.8 x 5.9 x 1.6 in) Weight 1.5 kg (3.30 lb) Note! The test conditions for the power consumption values provided above were as follows: Memory: 16 GB DDR4 3200 M.2: 64G OS: Windows 10 (64-bit) Software: Burn-In Test 8.1 PPC-306 EHL User Manual...
Ordering Information Table 1.2: Ordering Information Part Number Description Image ® ® PPC-306-RN6A Panel PC with Intel Celeron J6412 96PSA-A90W19OT-3 Power adapter 100 ~ 240 V , 90 W, 19V PPC-WLAN-D2 Wi-Fi module with antenna PPC-ARM-A03 Arm mount VESA standard PPC-174T-WL-MTE Wall mount kit PPC-Stand-A1E...
Chapter System Installation and Setup Quick System Tour Memory Card Installation M.2 Installation Wireless LAN Card Installation Mounting the System...
Before setting up the panel PC, take a moment to identify the locations of the device controls, drives, connectors, and ports (as shown in Figure 2.3). When placed upright, the PPC-306 EHL front panel should appear as shown in Figure 2.1. Figure 2.1 Panel PC Front View Figure 2.2 Panel PC Rear View...
E. COM1 RS232 F. DC-In G. Power Switch Installation Procedures When installing system hardware, adhere to the following order: Install the memory card. Install M.2 storage. Install peripheral devices. Mount the panel PC. Configure the system. PPC-306 EHL User Manual...
Insert the memory card into the corresponding slot on the main board, then place the thermal pad provided in the accessory box on top of the memory card and CPU. Remember to remove the protective film before using the thermal pad. Figure 2.5 Memory Card Installation Figure 2.6 PPC-306 EHL User Manual...
Remove the rear cover. Assemble the antenna bracket on the antenna cable. Figure 2.7 Assemble the Bracket with the Antenna Cable Assemble the Wi-Fi card and the thermal pad. Figure 2.8 Assemble the Wi-Fi Card and Thermal Pad PPC-306 EHL User Manual...
IEC/UL 60950-1 and/or IEC/UL 62368-1. The terminal block is suitable for 16 AWG min., with a torque value 4.5 lb-in min. Use copper conductors only. It must be installed by a trained and skilled person. PPC-306 EHL User Manual...
Drill two pilot holes at the marked locations on the wall. Align the wall mount plate screw holes with the pilot holes. Secure the mount plate to the wall by inserting screws into the two pilot holes and tightening them. Figure 2.10 Wall Mount Plate PPC-306 EHL User Manual...
Page 22
To mount the panel PC on the wall, align the wall mount bracket attached to the panel PC with the wall mount plate on the wall and slide the panel PC downward to hang the bracket on the mount plate. Figure 2.12 Mounting the Panel PC on a Wall PPC-306 EHL User Manual...
Insert the panel PC into the cutout. Retrieve the hook brackets and M6 x 21L screws from the accessory box. Veuillez installer le panneau PC dans la découpe. Récupérez les crochets et les vis M6 x 21L de la boîte à accessoires. Figure 2.14 Hook Brackets for Panel Mounting PPC-306 EHL User Manual...
Page 24
Figure 2.15 Locations of Hook Brackets Tighten the screws to secure the panel PC in place (Figure 2.26). Figure 2.16 Fasten the Hook Bracket Figure 2.17 Panel Mount Rear View (Take the PPC-321W drawing as example.) PPC-306 EHL User Manual...
Warning! Ensure that the thread depth of the screws on the rear panel does not exceed 4 mm (0.15 in). 2.3.4 Stand Mount Before assembling the stand mount, check that the product was shipped with the fol- lowing items: PPC-306 EHL User Manual...
Page 26
100 x 100 mm (3.93 x 3.93 in) VESA mount according to their require- ments. Figure 2.19 VESA Mount Screw Holes Use the four M4 x 8L screws to secure the base plate to the mount stand. Figure 2.20 Securing the VESA Mount Base PPC-306 EHL User Manual...
Page 27
Use four M4 x 6L screws to secure the mount stand to the VESA mount bracket. Figure 2.21 Securing the VESA Mount Bracket Use one M4 x 5L screw to secure the stand mount hinge cover. Figure 2.22 Securing the Stand Mount Hinge Cover PPC-306 EHL User Manual...
Install the PPC system into the cabinet. Figure 2.24 Install the PPC System into the Cabinet Step A: Connect the cabinet to the earth/ground. Step B: Embed the null PPC system into the cabinet without any I/O or power cables. PPC-306 EHL User Manual...
Page 29
AWG / 0.75 mm2 and connected to the earth of the building. Ensure that the voltage of the power source is correct before connecting the equipment to a power outlet by means of a power cord connected to a socket outlet with an earthing connection. PPC-306 EHL User Manual...
1-2pin AT power 3.1.4 Touch Power Selection Table 3.5: Touch Power Selection Function Open Closed Note! The resistive touch model needs a JP3 jumper added. The projected capacitive touch model should have the JP3 jumper removed. PPC-306 EHL User Manual...
COM1 Pin 9 is set as “RI” by default. This setting can be changed to 5V or 12V output using a jumper. COM2: RS-232/422/485 Note! COM2 does not support a ring function. Table 3.7: External COM Ports and Pin Definitions COM1 COM2 RS-232 RS-232 RS-422 RS-485 DATA- DATA+ Ring or 5V/12V output RING PPC-306 EHL User Manual...
When you install the system for the first time, please install the corresponding drivers in advance to make sure all the functions run normally. Please select the drivers to be installed based on the OS you use. Please go to the Advantech. BIOS Setup Utility 4.2.1...
4.2.2 Advanced BIOS Features Setup 4.2.2.1 CPU Configuration CPU Configuration View CPU model and frequency. PPC-306 EHL User Manual...
Page 38
4.2.2.2 COM2 Mode Selection (RS232/RS422/RS485) Select NCT6126D Super IO Configuration in the Advanced tab. Select Serial Port 2 Configuration option. PPC-306 EHL User Manual...
Page 39
Select Serial Port 2 Mode option to set the COM2 operation mode as RS232 RS422, or RS485. 1) Setting RS232 2) Setting RS422 PPC-306 EHL User Manual...
Page 40
3) Setting RS485 If COM2 mode is set as RS485, the RS485 Auto Flow control option can be Enabled or Disabled. 4.2.2.3 Hardware Monitor PPC-306 EHL User Manual...
Page 41
EC Hardware Monitor This page displays all information about system Temperature/Voltage/Current. 4.2.2.4 USB Configuration PPC-306 EHL User Manual...
Legacy USB Support Enable/Disable USB Mass Storage Driver Support 4.2.3 Chipset Configuration 4.2.3.1 Wake-on-LAN Select PCH-IO Configuration option in the Chipset tab. PPC-306 EHL User Manual...
Page 43
Set the Wake On By option to Enabled. 4.2.3.2 Deep Sleep Select PCH-IO Configuration option in the Chipset tab. PPC-306 EHL User Manual...
Set the Deep Sleep by option to Enabled/Disabled for ERP 4.2.4 Security Administrator Password Set Administrator Password. PPC-306 EHL User Manual...
This means the default boot selec- tion is not automatically started by the firmware. Bootup NumLock State Select the keyboard NumLock state. Quiet Boot Enables or disables Quiet Boot option. Boot Option #1 Sets the system boot order. PPC-306 EHL User Manual...
This item allows users to restore/load default values for all setup options. Save as User Defaults This item allows users to save all current settings as user defaults. Restore User Defaults This item allows users to restore all setup options to the user default values. PPC-306 EHL User Manual...
