SIMS Deltec CADD-1 5100 HFX Operator's Manual page 17

NOTE:
Be sure to m atch the polarity m ark ings of the new
battery (+ and –) w ith those on the battery
com partm ent. If you put the battery in back w ards,
the display panel w ill be blank , and you w ill not hear
a beeping sound.
Use a new, 9-volt alkaline or lithium battery to power
the pump. You may use any alkaline battery, including
®
DURACELL Alkaline M N 1604 and EVEREADY
®
EN ERGIZ ER
the ULTRALIFE
also use an external power source to run the pump.
STEP 4: Place the battery door halfway over the battery
compartment and press the battery into the
compartment by pushing down on top of the
door with your thumb.
STEP 5: Slide the door closed. Ensure that the door is
latched by trying to remove the door without
pressing the release button.
WARNING:
If a gap is present anyw here betw een the battery door and the pump housing,
the door is not properly latched. If the battery door becomes detached or loose,
the batteries w ill not be properly secured; this could result in loss of pow er,
nondelivery of drug, and, depending on the type of drug being administered,
death or serious injury to the patient.
The power up sequence will start, and the pump will go through an electronic
self-test, which lasts about 50 seconds. All of the display indicators and the
software revision level will appear briefly.
Alkaline #522, for example; or, use
® Lithium U9VL batter y. You may
®
11/26/96
D. Zurn
Close
Locking
Door
11/96
11
