1 Overview

The ADS8354EVM-PDK evaluation kit includes the ADS8354EVM board and the precision host interface (PHI)
controller board that enables the accompanying computer software to communicate with the ADC over the USB
for data capture and analysis.
The ADS8354EVM board includes the ADS8354 SAR ADC, all the peripheral analog circuits, and the
components required to achieve optimum performance from the ADC.
The PHI controller board primarily serves three functions:
• Provides a communication interface from the EVM to the computer through a USB port
• Provides the digital input and output signals necessary to communicate with the ADS8354 device
• Supplies power to all active circuitry on the ADS8354EVM board
Along with the ADS8354EVM and PHI controller board, this evaluation kit includes an A-to-micro-B USB cable to
connect to a computer.

1.1 ADS8354EVM-PDK Features

The ADS8354EVM-PDK showcases the following features:
• Hardware and software required for diagnostic testing and accurate performance evaluation of the ADS8354
ADC
• USB powered—no external power supply is required
• The PHI controller board provides a convenient communication interface to the ADS8354 ADC over USB 2.0
(or higher) for power delivery and digital input and output
• Easy-to-use evaluation software for Microsoft

1.2 ADS8354EVM Features

The ADS8354EVM showcases the following features:
• Onboard low-noise, low-distortion ADC input drivers optimized to meet ADC performance
• Onboard ultra-low noise, low-dropout (LDO) regulators to generate supplies for the operation amplifiers and
ADC

1.3 Related Documentation From Texas Instruments

The documents in Table 1-1
assembly of the ADS8354EVM-PDK. This user's guide is available from the TI web site under literature number
SBAU407. Any letter appended to the literature number corresponds to the document revision that is current at
the time of the writing of this document. Newer revisions may be available from the TI web site at www.ti.com,
or call the Texas Instruments Literature Response Center at (800) 477-8924 or the Product Information Center at
(972) 644-5580. When ordering, identify the document by both title and literature number.
SBAU407 – APRIL 2023
Submit Document Feedback
® Windows
provide information regarding Texas Instruments integrated circuits used in the

Table 1-1. Related Documentation

Device
ADS8354 product data sheet
THS4561 product data sheet
OPA320 product data sheet
TPS7A47-Q1 product data sheet
REF6025 product data sheet
LM7705 product data sheet
Copyright © 2023 Texas Instruments Incorporated
® 7, 64-bit operating systems
Literature Number
SBAS556
SBOS874
SLOS884
SBVS118
SBOS708
SNVS420
ADS8354EVM-PDK Evaluation Module
Overview
3
