Comtech EF Data CPA-050 Installation And Operation Manual page 82

C-Band Solid-State Power Amplifier
Remote Control Commands
Packed Utility Packed Utility Status:
Status Confirmation:
Packed Alarm Packed Alarm Status:
Status Confirmation:
CPA-050
Packed Alarm Packed Alarm Status:
Status Confirmation:
CPA-100/200
Packed Alarm Packed Alarm Status:
Status Confirmation:
CPA-350
<DEV/PACRUS_'cr'
>DEV/PACRUS_abbcdeeff'cr'' lf']
<DEV/PACRAS_'cr'
>DEV/PACRAS_abcdefghijk'cr'' lf']
<DEV/PACRAS_'cr'
>DEV/PACRAS_abcdefghjkl'cr'' lf']
<DEV/PACRAS_'cr'
>DEV/PACRAS_abcdefghijklmn'cr'' lf']
29
Revision 0
MN/CPA-IN.IOM
Where:
a = COM1 Mode; 0 =EIA-232,
1 = EIA-485-2; 2 = EIA-485-4
bb = Address in Hex (01 to FF)
c = 0 if Baud Rate = 9600
1 if Baud Rate = 4800
2 if Baud Rate = 2400
3 if Baud Rate = 1200
4 if Baud Rate = 300
d = 0 if Parity Even, 1 if Parity Odd
ee = LCD Contrast (0 to 30)
ff = LCD Brightness (0 to 30)
Where:
a = 1 if +28 Fault, else 0
b = 1 if +12 Fault, else 0
c = 1 if –12 Fault, else 0
d = 1 if + 5 Fault, else 0
e = 1 if – 5 Fault, else 0
f = 1 if + 10V PS1 Fault, else 0
g = 1 if + 10v PS2 Fault, else 0
h = 1 if TEMP Fault, else 0
i = 1 if FAN1 Fault, else 0
j = 1 if FAN2 Fault , else 0
k = 1 if PROC Fault, else 0
Where:
a = 1 if +28 Fault, else 0
b = 1 if +12 Fault, else 0
c = 1 if –12 Fault, else 0
d = 1 if + 5 Fault, else 0
e = 1 if – 5 Fault, else 0
f = 1 if + 10V PS1 Fault, else 0
g = 1 if + 10v PS2 Fault, else 0
h = 1 if TEMP Fault, else 0
j = 1 if FAN1 Fault, else 0
k = 1 if FAN2 Fault , else 0
l = 1 if PROC Fault, else 0
Where:
a = 1 if +28 Fault, else 0
b = 1 if +12 Fault, else 0
c = 1 if –12 Fault, else 0
d = 1 if + 5 Fault, else 0
e = 1 if – 5 Fault, else 0
f = 1 if + 10V PS1 Fault, else 0
g = 1 if + 10v PS2 Fault, else 0
h = 1 if TMP1 Fault, else 0
I = 1 if TMP2 Fault, else 0
j = 1 if Isolator Load Overheat, else 0
k = 1 if SHTD Fault, else 0
l = 1 if FAN1_2 Fault, else 0
m = 1 if FAN3_4 Fault , else 0
n = 1 if PROC Fault, else 0
