C-Band Solid-State Power Amplifier
Remote Control Commands

6.7.6 Time-Outs

A time-out should be assumed if there is no response in 1.0 seconds. The station monitor
and control computer should try at least three times. Possible sources of time-outs are
listed in Table 6-2
6.8

Command Summaries

Table 6-3 and Table 6-4 summarize the remote control commands and commands
supported by virtual addressing mode.
Commands
Set Time
Set Date
Set Physical Address
Set Baud Rate
Set Parity Rate
Set LCD Contrast
Set LCD Brightness
Retrieve Equipment type
Set Local/Remote state
Set Application ID Message
Set Amplifier On/OFF
Mute/Unmute
Set Attenuation
Select Auto Fault Recovery
Select Auto/Manual Mode
Forced Backup Mode
Select Priority
Table 6-2. Possible Time-Out Sources
Incorrect Device Address
Faulty Cable
Faulty Connector
I/O fault on remote interface
I/O fault on monitor and control computer
Table 6-3. Remote Control Summary
Display
Utility
<DEV/TIM_hh:mm:ss
<DEV/DAT_mm/dd/yy
<DEV/SPA_xxx
'cr'
<DEV/SBR_xxxx
'cr'
<DEV/SPB_xxxx
'cr'
<DEV/CON_xx
'cr'
<DEV/LCD_xx
'cr'
<DEV/RET_
'cr'
<DEV/LRS_x
'cr'
<DEV/AID_xxx...xxx
Configuration Commands
<DEV/AMP_xxx
'cr'
<DEV/MUT_xxx
'cr'
<DEV/ATT_xx.xx
'cr'
<MDEV/AFR_xxx
Redundancy Mode Commands
<DEV/SAM_y
'cr'
<DEV/FBU_x_y
'cr'
<DEV/PRI_x
'cr'
31
'cr'
'cr'
'cr'
'cr'
Revision 0
MN/CPA-IN.IOM
Remarks
