Comtech EF Data CPA-050 Installation And Operation Manual page 81

C-Band Solid-State Power Amplifier
Remote Control Commands
Packed Packed Maint Status:
Maintenance Confirmation
Status
CPA-050
Packed Packed Maint Status:
Maintenance Confirmation:
Status
CPA-100/200
Packed Packed Maint Status:
Maintenance Confirmation:
Status
CPA-350
<DEV/PACRMS_'cr'
>DEV/PACRMS_aabbccddeeffgghhhiii'cr'' lf']
<DEV/PACRMS_'cr'
>DEV/PACRMS_aabbccddeeffgghhhiijjji'cr'' lf']
<DEV/PACRMS_'cr'
>DEV/PACRMS_aabbccddeeffgghhhiijjjikkklll'cr''
lf']
28
Revision 0
MN/CPA-IN.IOM
100mV per count
Where:
aa = + 28 VDC supply, 100mV per
count above 10.0V in Hex
bb = + 12 VDC supply scaled 100 mV
per count in Hex
cc = - 12 VDC supply scaled 100mV
per count in Hex
dd = + 5 VDC supply scaled –100mV
per countin Hex
ee = - 5 VDC supply scaled –100mV
per count in Hex
ff = + 10 VDC supply #1 scaled 100 mV
per count in Hex
gg = Signed temperature in°C
(-10 to +95)
hhh= RF forward power, 0.1 dBm steps
above 15.0 dBm in Hex
iii = RF reverse power, 0.1 dBm steps
above 10.0 dBm in Hex
Where:
aa = + 28 VDC supply, 100mV per
count above 10.0V in Hex
bb = + 12 VDC supply scaled 100 mV
per count in Hex
cc = - 12 VDC supply scaled 100mV
per count in Hex
dd = + 5 VDC supply scaled –100mV
per countin Hex
ee = - 5 VDC supply scaled –100mV
per count in Hex
ff = + 10 VDC supply #1 scaled 100 mV
per count in Hex
gg = + 10 VDC supply #2 scaled 100
mV per count in Hex
hhh = Signed temperature in degrees C
(-10 to +95)
iii = RF forward power, 0.1 dBm steps
above 15.0 dBm in Hex
jjj = RF reverse power, 0.1 dBm steps
above 10.0 dBm in Hex
Where:
aa = + 28 VDC supply, 100mV per
count above 10.0V in Hex
bb = + 12 VDC supply scaled 100 mV
per count in Hex
cc = - 12 VDC supply scaled 100mV
per count in Hex
dd = + 5 VDC supply scaled –100mV
per count in Hex
ee = - 5 VDC supply scaled –100mV
per count in Hex
ff = + 10 VDC supply #1 scaled 100 mV
per count in Hex
gg = + 10 VDC supply #2 scaled
100 mV per count in Hex
hhh = Signed temperature of module 1
in degrees C (-10 to +95)
iii = Signed temperature of module 2
in degrees C (-10 to +95)
jjj = Signed temperature of isolator load
in degrees C (-10 to +95)
kkk = RF forward power, 0.1 dBm steps
above 26.0 dBm in Hex
lll = RF reverse power, 0.1 dBm steps
above 19.0 dBm in Hex
