URL URL the channel is being streamed to.
Frames Number of frames sent from encoder to channel since the beginning of encoding. This can
serve as a quick sanity check. (For example, you can click "Refresh", count to 10, click
"Refresh" again, and you should see an increase of around 600 for 60 frames per second
content).
Input Status
Input HDMI1 refers to the captured content from the camera lens.
Resolution Capture resolution for video.
FPS Capture frames per second for video.
Temperature Status
Sensor There are three temperature sensors: lens, FPGA chip and CPU chip.
Temp Sensor readings in degrees Celsius.
(Celsius)
Parameter Options (default in bold)
Refresh N/A
Button
Auto Checked
Refresh
Unchecked

10.5 The Video Tab

Parameter Options
(Default in
bold)
Preview Image/Stream
Load Button
Start Button
Stop Button
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8
Description
Click button to manually refresh information.
Sets whether the status tab will automatically refresh
information.
Description
Click to view a still preview image of camera video in the user interface. If a
preview stream is currently running click the Stop button to enable this
button.
Click to start a live preview of camera video in the user interface.
Click to stop the live preview of camera video in the user interface. Live
preview will auto stop when leaving the tab.
th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
57
ZCube-SC User Guide
DOC-USR-0265-01
