Figure 24 Facebook Live Stream Encoder Settings - Z3 Technology ZCube-SC User Manual

(5) Enter the Server URL minus the protocol header and stream Key as a continuous string in the
Dest Address field. In our example, the full address reads
api.facebook.com:443/rtmp/10105999705404285?s_sw=0&s_vt=api-s&a=Abyv0xFhiC6Wrgo9".
Authentication should remain disabled.
(6) Click Start or Start All to begin encoding stream.
(7) Return to the Facebook Live Video Setting dialog box to ensure your stream is previewing properly.
Add a message to the video stream, if desired, and click Go Live at the bottom. Your Stream is now
active!
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8

Figure 24 Facebook Live Stream Encoder Settings

th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
"live-
Enter Server URL and
Stream Key
30
ZCube-SC User Guide
DOC-USR-0265-01
Set to "RTMPS"
