Time Settings
Enable Time None, Network Time
Service Protocol (NTP)
Time Zone America/Chicago
pool.ntp.org
NTP Servers
PTP Auto, Client only,
Server/Client Server only
Role
Enable NTP True
False
Time Zone America/Chicago
NTP Servers (128.138.141.172)
Set HTTP/HTTPS
Set 802.1X
Configure FPGA*
Configure ONVIF*
Configure ONVIF
VMD*
Detection Channel 1
Channel
Checked, Unchecked
Modify Zone
1-100 (1)
Sensitivity
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8
Must match previous field.
Click this button to access Time configuration options.
Sets desired time service on the unit.
Allows for selection of desired time zone.
Address of desired server for NTP.
Sets the PTP role; see DOC-USR-0223-0x for details.
Sets whether Network Time Protocol (NTP) is enabled.
Allows for selection of desired time zone.
Address of desired server for NTP.
Sets HTTP/HTTPS access to the web UI. See DOC-USR-0164-
0x for more information.
Sets configuration for 802.0x on the wired connection. See
DOC-USR-0161-0x for details.
Configures FPGA config for unit. Z3 ships units with expected
FPGA config, but changes to the hardware configuration of
product may require a change to the FPGA config. Most
customers will not need change this setting.
Enable/Disable ONVIF and control number of cameras to
advertise to ONVIF clients.
Click this button to set up video motion detect and image
too dark detect ONVIF notifications.
Sets the channel to use for motion detection.
Allows setting of a detection zone within the video.
Sets the sensitivity of the video motion detect higher
numbers are more sensitive.
