ZCube-SC User Guide
DOC-USR-0265-01
(3) The output resolution can be adjusted in real time. In the System Setup tab, select the desired
option from the Resolution dropdown menu under the Display Setup section.
(4) Click the Set Display button for changes to take effect.
Select Resolution Option
Click "Set Display"
Figure 36 Set HDMI Pass-Through Resolution
39
