The User Presets Tab - Z3 Technology ZCube-SC User Manual

Enable Too Dark TRUE, FALSE
Detect
Threshold 1-100 (85)
Set Term Server*
Set ZFinder*
Set DDNS
Enable DDNS TRUE, FALSE
DDNS Provider Assorted
DDNS Username
DDNS Password
DDNS Hostname
Update device
firmware Button
Download
support logs
Button
Reboot Button

10.2 The User Presets Tab

Button Notes
new Define a new configuration file.
Up to nine configurations can be created.
rename Rename a configuration file.
delete Delete a configuration file.
export Export current settings to a file.
import Load settings from a previously exported file.
Reset Resets presets.
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8
Enables Video Too Dark Tamper detection notification from
ONVIF.
Sets the percent darkness of the image to trigger the too
dark detect. Lower values mean higher sensitivity.
Enable/Disable remote terminal server.
Enable/Disable ZFinder support on unit.
Click this button to set up Dynamic Domain Name System
(DDNS).
Enable/Disable DDNS.
Select DDNS service provider from a list of supported
providers
Username for DDNS service provider.
Password for DDNS service provider.
DDNS hostname provided by DDNS service provider.
Access the Software Updater to update the firmware on your
device. An image file of the desired firmware is needed.
Extract a set of diagnostic logs that can be provided to Z3 in
the event of an issue to be reported. The resulting file is
saved on the PC with the user interface open.
Restarts the unit without the need to disconnect power.
55
th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
ZCube-SC User Guide
DOC-USR-0265-01
