6.5.3 Recommended Settings:
When streaming HD video in HEVC/H.265 mode, the following recommended settings can be used for
the best results:
Output Rate
Format Control
RTSP CBR
TSRTP CBR
UDP CBR

6.6 Stream Multiple Resolutions

The ZCube-SC supports simultaneous encode into up to three different resolutions, bitrates and output
formats. Each output stream can be set using a separate channel tab. If the CH2 tab is not present, you
can create a second channel by clicking on the

6.7 Setting NTP

The ZCube-SC has support for NTP to set the time on the unit. If you require the system time to be set do
the following:
(1) Load the web UI of the unit and switch to the System Setup tab. Click the go button next to Time
Settings.
(2) Select Network Time Protocol (NTP) from the Enable Time Service dropdown.
Note: If PTP (IEEE-1588) is required see DOC-USR-0223-0X.
(3) Select the desired time zone for the unit form the Time Zone dropdown.
(4) Enter an NTP server address. The default is
(5) Click the change button. NTP is now enabled and your system clock will be adjusted.
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8
VLC Network
Bitrate
Cache
2 Mbps 300 ms
3 Mbps 1000 ms
3 Mbps 1000 ms

Figure 28 Recommended Settings

Figure 29 Create Additional Output Channels

th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
Notes
Best latency (approx. 400 ms), no frame skips
@ 300 ms, frame skips; @ 1000 ms, no frame skips
@ 300 ms, frame skips; @ 1000 ms, no frame skips
+
tab.
Click the "+" Tab
pool.ntp.org (NIST).
33
ZCube-SC User Guide
DOC-USR-0265-01
