8.2.2 Access Advanced Settings
(1) Under Device Setup, check the Advanced Settings box.
(2) Click on the Save button.
(3) A pop-up window appears with a message that the settings were saved successfully.
(4) Return to your channel tab to set additional encoding configuration parameters for your stream. See
Section 10.7, The CH1 Tab (Channel 1), for more information on the advanced settings available for
each streaming output.

Figure 41 Default RTSP Settings (Left) and Advanced RTSP Settings (Right)

______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8
(1) Check "Advanced Settings"

Figure 40 Accessing Advanced Settings

43
th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
(2) Click "Save"
