8.0 PERFORMING OTHER OPERATIONS WITH THE ZCube-SC

8.1 Save Current Settings

If you have a specific configuration you'd like to preserve, you can save it so that when the ZCube-SC is
powered off and back on, it automatically boots to those settings.
(1) In the preset dropdown menu located at the bottom of any screen, select --- new preset ---.
(2) A textbox will appear. Enter your desired preset name. In the pictured example, z3_config1 is used.
(3) Click ok.
(1) Type New Preset Name
(4) Select your newly created configuration from the preset dropdown menu at the bottom of the
screen.
(5) As soon as you select z3_config1, the screen will reload.
(6) Change your desired settings.
(7) Once your changes have been set in this configuration, click on the Save button.
(8) A pop-up window appears to confirm the saving of these settings is complete. Click OK.
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8
Select "--- new preset ---"

Figure 37 The User Presets Tab

Figure 38 Entering a User Preset Name

Figure 39 Saving a User Preset

41
th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
(2) Click "ok"
Click "Save"
ZCube-SC User Guide
DOC-USR-0265-01
