Selected Motor Display; Manual Motor Movement - ETC QuickTouch+ Mk2 User Manual

• Blinking green: Motor moving down
• Blinking white: Trim being recorded
• Alternating red and other: Error (see
• Alternating yellow and other: Informational messages
• LED dim: Motor not selected
• LED off: Inactive button / no motor assigned

Selected Motor Display

On selection of a motor, the LCD will display the status screen for that motor. If multiple
motors are selected, the status screen for the last selected motor will be displayed.
B A
C
D

Manual Motor Movement

To move the selected motor or motors, press and hold the Up
releasing a move button, all selected motors stop moving.
Note:
If both buttons are pressed and held at once, the motors do not move. If
conflicting directions are pressed simultaneously from different controllers (i.e., Up on
the QuickTouch+ Mk2 and Down on a remote control), the motors do not move.
All selected motors stop when:
• The Up
• Any single selected motor produces a fault or error
An individual motor may stop moving when:
• It reaches a trim position.
• It reaches a limit position.
If individual motors stop due to a trim or limit being reached, all other selected motors still
within their set range of travel continue to move normally.
10
H
G
E F
or Down button is released
Status Messages on page 17
A Current position
B Channel number
C Channel name
I
D Current Load, Trim, and Speed
Bar graph of current position in
E
travel range
Bar graph of current load in load
F
range
Location of current trim in travel
G
range
H Recorded load marker
I Location of high trim
)
or Down button. Upon
QuickTouch+ Mk2 User Guide
